Screw Feed Aluminum Dust/ Powder Briquetting Machines

Specifications

1. High profit and low cost in raw material
2. Increase the net calorific value per unit volume after briquette
3. Energy save

     Screw Feed Aluminum Dust/ Powder Briquetting Machines



Coal briquette machine:



This machine is widely used to recycling the mineral wastes, and processes them into briquettes for re-use. Due to the large quantity of materials resources, based on different materials density, we have developed several types of briquette machine, mechanical pressure briquette machine, hydraulic pressure briquette machine and strong pressure briquette machine with screw feeder.



The applicable material is very wide, such as iron powder, coal powder, charcoal powder, coke powder, many kinds of ferrous and non-ferrous metal ores, fireclay material, and other industrial tailing wastes. All of these materials could be compress into briquettes.



Please tell me that your raw materials, I can give you some suggestions on the pressure of briquette machine.



Model: HSYQ-750

Power: 55-75 kw (three phases, 380V, 50HZ)

Discharging belt conveyor power: 3kw

Diameter of roller:750mm

Width of the roller: 370mm

The largest pressure: 20T

Coal capacity: 13-18t/h

Coke capacity: 13-18t/h

Charcoal Capacity: 6.5-9t/h

Final briquette diameter: 30-50mm

Material of roller:65Mn

Lifetime of the roller: about 1 year

Diameter of the gearbox: 850mm

Applicable materials: cola, charcoal, metal powder, etc.

Shape of final products: ball, pillow,bread,etc.

Mode of Operation:Four Rollers Squeezing

Weight: 9800 kg

Pack size: 3*2.5*2.1 m



Final briquettes:
