Mineral Powders Briquette Press Machine With Screw Feed

Mineral Powders Briquette Press Machine With Screw Feed photo-1
US$ 2,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Motor Type:
AC Motor
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai etc.
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Motor Type AC Motor
Place of Origin Henan, China
Brand Name E.P
Model Number HSYQ
Certification ISO; CE
Warranty ONE YEAR
After-sales Service Provided Overseas third-party support available

Specifications

1. High profit and low cost in raw material
2. Increase the net calorific value per unit volume after briquette
3. Energy save

     Mineral Powders Briquette Press Machine with Screw Feed



Coal briquette machine:



This machine is widely used to recycling the mineral wastes, and processes them into briquettes for re-use. Due to the large quantity of materials resources, based on different materials density, we have developed several types of briquette machine, mechanical pressure briquette machine, hydraulic pressure briquette machine and strong pressure briquette machine with screw feeder.



The applicable material is very wide, such as iron powder, coal powder, charcoal powder, coke powder, many kinds of ferrous and non-ferrous metal ores, fireclay material, and other industrial tailing wastes. All of these materials could be compress into briquettes.



Please tell me that your raw materials, I can give you some suggestions on the pressure of briquette machine.



Model: HSYQ-750
Power: 55-75 kw (three phases, 380V, 50HZ)
Discharging belt conveyor power: 3kw
Diameter of roller:750mm
Width of the roller: 370mm
The largest pressure: 20T
Coal capacity: 13-18t/h
Coke capacity: 13-18t/h
Charcoal Capacity: 6.5-9t/h
Final briquette diameter: 30-50mm
Material of roller:65Mn
Lifetime of the roller: about 1 year
Diameter of the gearbox: 850mm
Applicable materials: cola, charcoal, metal powder, etc.
Shape of final products: ball, pillow,bread,etc.
Mode of Operation:Four Rollers Squeezing
Weight: 9800 kg
Pack size: 3*2.5*2.1 m



Final briquettes:

Mineral Powders Briquette Press Machine with Screw FeedMineral Powders Briquette Press Machine with Screw Feed

Mineral Powders Briquette Press Machine with Screw Feed

Mineral Powders Briquette Press Machine with Screw FeedMineral Powders Briquette Press Machine with Screw Feed
