Specifications
1. High profit and low cost in raw material2. Increase the net calorific value per unit volume after briquette
3. Energy save
Widely-used Dry Mineral Dust Powder Briquette Machine
The briquette machine is used to recycling the mineral powder, or dust, and the metal dust/ powder, and other industrial tailing wastes. This briquette machine have multi-function, it is very widely used in mine plants, especially in coal mine, iron mine, and other natural resources mine.
The available materials list can be:
a. Mineral powder: coal, charcoal, coke, lignite, brown coal, white coal, and other mineral powder.
b. Metal powder: iron powder, iron ores, bronze powder, brown iron and other metal waste powders.
c. Some materials with light density: lime powder, aluminum powder, aluminum dust, etc.
d. Other industrial tailing wastes for recycling.
the briquette machine has two conditions of feeding materials:
1. the size no more than 5mm.
2. the mositure should be about 8-10%.
Here are some main technical parameters:
Model | Capacity (T/h) | Power (kw) | Pre-press power (kw) | Motor power (kw) | Roller material |
HSYQ-400 | 2-3 | 45 | 15 | 1.8 | 65Mn |
HSYQ-520 | 3-5 | 55 | 15 | 1.8 | 65Mn |
HSYQ-650 | 5-6 | 75 | 22 | 1.8 | 65Mn
|
HSYQ-700 | 6-7 | 75 | 18.5 | 1.8 | 65Mn
|
HSYQ-740 | 7-8 | 90 | 18.5 | 1.8 | 65Mn
|
HSYQ-750 | 8-9 | 110 | 18.5 | 1.8 | 65Mn |
Final briquettes:
Note: please tell me about your raw material, I will offer you more details and information. Thank you!
