Rice Husk Briquette Fuel Making Machine
Introduction:
Rice husk briquette fuel making machine is the main equipment to make stick solid fuel with such biomass material as bits of wood, rice shell,coffee husk,peanuts shell, bagasse,etc. The raw material(12% Water proportion) dried by the dryer(12% humidity)will be formed into fuel under high pressure and at high temperature.
Working Principle:
The briquette making machine uses a large screw to grind, compress and extrude the biomass into briquettes. The natural lignin content in biomass is liberated with wood fiber under high pressure and temperature.In the briquetting process lignin serves as the glue and combines the particles of wood together,thus binding, compressing the biomass to form into various moulds of high density briquette, such as hexagonal,quadrangular, square,etc. As your requirement, we can also change the shape to order. And the diameter of briquettes are from 30-90 mm. Moreover non-binder needs to be used during this process.
Datas:
Model |
Power(kw) |
Capacity(kg/h) |
Dia of Briquettes(mm) |
Size(m) |
Weight(kg) |
HSZB-01 |
15+6 |
180-210 |
30,40,50 |
1.8x0.76x1.29 |
540/590 |
HSZB-02 |
11+6 gearbox |
180-210 |
30,40,50 |
1.8x0.76x1.29 |
570/610 |
HSZB-03 |
22+9 |
350-400 |
60,70,80,90 |
1.96x0.88x1.62 |
1000/1100 |
HSZB-04 |
22+9 gearbox |
350-400 |
60,70,80,90 |
1.96x0.88x1.62 |
1200/1300 |
Send Inquiry to This Supplier
