200kg/h wood briquette extruder/ wood briquette press machine
Wood charcoal extruder is used to press sawdust into hexagonal shape or round shape briquettes. The briquettes has high density and heating value.
After getting the wood briquettes, you can burn them direclty or make them into charcoal.
The diameter of the wood logs can be 40mm to 90mm as you want.
Please see more details as following:
| Model | Power(kw) | Capacity kg/h | Dia of Briquettes | Size(m) | Weight(kg) |
| HSZB-01 | 15+6 | 180-210 | 40,50mm | 1.8x0.76x1.29 | 540/590 |
| HSZB-03 | 22+9 | 350-400 | 60,70,80,90mm | 1.96x0.88x1.62 | 1000/1100 |
| HSZB-04 | 22+9 gearbox | 350-400 | 60,70,80,90mm | 1.96x0.88x1.62 | 1200/1300 |
Requriment of raw materials:
For the raw materials fed into the briquette machine, it should be powder type with size less than 5mm. If it is bigger than 5mm, you should crush them firstly. The moisture of the materials should be less than 15%. If its moisture is higher, you should dry it by a dryer.
In the following are photos of briquettes made by our machine:
