The pioneer of environmental protection--An ideal waste solution supplier
Textile waste baler hydraulic waste coarse linen clothes baler machine
1.Product introduction:
- It adopts vertical frame with hydraulically lifted chamber, convenient to tie bales and enhances efficiency.
- Electrical button centrally controlled, easy and safe to operate.
- Suitable for roducts in need of outer packaging, bales are trapped in '#' shape.
- Applicable to used clothes, wool, fiber, rags and other textiles.
2. Machine parameter:
Model |
JP120LT |
Name |
Textile waste baler hydraulic waste coarse linen clothes baler machine |
Hydraulic power (Ton) |
120 |
| Bale size (L*W*H mm) | 1100*800*(500-1250) |
Feed opening size (L*H mm) |
1100*600 |
Chamber size (L*W*H mm) |
1100*800*1650 |
Bale weight (Kg) |
350-550 |
Machine size (L*W*H mm) |
1850*1200*4680 |
Brand |
CSJ |
Voltage (customizable) (V/HZ) |
380V / 50HZ |
Power (Kw/Hp) |
22Kw/30Hp |
Machine weight (Kg) |
4200 |
3.Brand Of Baler Parts:
Crucial Components Allocation | |
HYDRAULIC TECHNIQUE |
REXROTH (Germany TECHNIQUE) |
HYDRAULIC ELEMENTS |
YUTIEN,HYDOR (TAIWAN Brand) |
SEALING PARTS |
HALLET (UK brand) |
ELECTICAL ELEMENTS |
DELIXI (Europe brand ) |
OIL PIPE |
ZMTE (Europe brand) |
MOTOR |
JIABAO (Brand-specific Customized hydraulic motor, without junction axis ,lower noise, no maintenance and energy saving, safe and reliable |
PUMP |
JINGGONG (Taiwan investment) |
4.Details of machine photoes:
5.Models for options:
Model |
Hydraulic power(Ton) |
Bale size (L*W*H mm) |
Feed opening size (L*H mm) |
Chamber size (L*W*H mm) |
Bale weight(KG) |
Voltage(customizable) (V / HZ) |
Power (Kw / Hp) |
Machine size (L*W*H mm) |
Machine weight (Kg) |
JP30LT |
30 |
600*400*(400-600) |
600*460 |
600*400*1200 |
40-60 |
380 V/50HZ |
7.5kw/10hp |
1300*760*3780 |
1800 |
JP50LT |
50 |
760*520*(400-800) |
760*460 |
760*520*1250 |
80-120 |
380 V/50HZ |
11kw/15hp |
1500*880*3780 |
2300 |
JP60LT |
60 |
1000*700*(400-800) |
1000*460 |
1000*700*1250 |
150-200 |
380 V/50HZ |
11kw/15hp |
1700*1000*3780 |
2800 |
JP80LT |
80 |
1100*800*(400-900) |
1100*460 |
1100*800*1250 |
200-300 |
380 V/50HZ |
15kw/20hp |
1850*1200*3800 |
3500 |
JP120LT |
120 |
1100*800*(500-1250) |
1100*600 |
1100*800*1650 |
350-550 |
380 V/50HZ |
22kw/30hp |
1850*1200*4680 |
4200 |
JP150LT |
150 |
1100*100*(700-1450) |
1100*700 |
1100*1000*1950 |
450-600 |
380 V/50HZ |
30kw/40hp |
1900*1600*5250 |
5800 |
6.Certification:
7.Production process:
8.Packing for shipment:
9.In exhibition:
10.About us:
- Jiajing(CSJ)’s factory is located in Nantong, Jiangsu Province and our marketing department is located in Shanghai.
- We are commited in the research and development of hydraulic balers since 1995, our target is to do the latest, the most fashionable and the most high-end product.
- Our product which has 7 series about 50 size has widely used in paper making,textile,commodities,food etc..
- Got CE ISO TUV SGS and so on Certifications
- We are the supplier of Nike, Wal-mart, Unicharm, Dumex, JNJ,RT-Mart and many other World famous manufactures and wholesalers.
11.Our service:
- One year warranty for whole machine.
- Engineers available to service machinery overseas.
- 24 hours technical support by e-mail.
