3-15 LPM Industrial Oxygen Generator / Oxygen Generator Price
3-15 LPM industrial oxygen generator / oxygen generator price
NT-OX series oxygen generators use the characteristic of special molecular sieve to separate the oxygen from the air and remove harmful substance for high purity industrial oxygen product by thetechnology of pressure swing adsorption(PSA).
3-15 LPM industrial oxygen generator / oxygen generator price
Specification:
Item |
Unit |
NTOX3AL |
NTOX5AL |
NTOX7AL |
NTOX10AL |
NTOX15AL |
Oxygen output |
LPM |
3 |
5 |
7.5 |
10 |
15 |
Oxygen concentration |
% |
90%±3% |
90%±3% |
90%±3% |
90%±3% |
90%±3% |
Air flow rate |
LPM |
36-45 |
60-75 |
90-115 |
90-115 |
180-200 |
Pressure(inlet) |
Mpa |
0.14-0.18 |
0.14-0.2 |
0.15-0.21 |
0.18-0.25 |
0.35 |
Pressure(outlet) |
Mpa |
0.06-0.08 |
0.06-0.08 |
0.06-0.08 |
0.06-0.08 |
0.06-0.08 |
Temperature |
℃ |
indoor temperature |
||||
Relative humidity |
% |
≤ 70%±10% |
||||
Noise |
Db |
≤60 |
≤60 |
≤60 |
≤60 |
≤60 |
Dimension |
mm |
200×310 |
200×430 |
200×500 |
200×560 |
200×880 |
Net weight |
kg |
5.5 |
7 |
8 |
11 |
12.5
|
