Help CenterSteel Cable Carrier
Related Products
steel cable carrier's feature:
1.suitable for installing a large quantity and heavy cables ,oil pipes,or gas pipes
2.allow suspending installation,not need supporting
3.big length is allowed
4.different supporting board : SLS(form supporting board)SLP(plastic spacer) SLA(aluminium alloy supporting board)
5. supporting plate type:intergrated type,combinated type,frame type
6.TLG cable chain's size
type |
Bending radius |
pitch |
Max aperture |
Chain’s H |
Chain thickness |
Divider plate thickness |
The distance between hoses on the connector |
The hose diameter on the connector |
TLG20 |
75.100.150.200.250.300 |
75 |
32 |
50 |
8 |
3.5 |
30 |
90 |
TLG30 |
115.150.200.250.300.400 |
100 |
50 |
75 |
10 |
3.5 |
50 |
11 |
TLG40 |
185.200.250.300.400.500 |
125 |
70 |
100 |
14 |
3.5 |
70 |
13 |
TLG50 |
250.300.400.500.600 |
175 |
118 |
150 |
14 |
4.5 |
115 |
13 |
TLG50’ |
250.300.400.500.600 |
180 |
118 |
150 |
14 |
4.5 |
115 |
13 |
