Biomass reed briquette machine
1.Biomass reed briquette machine can make waste of animals and agriculture like rice husk, corn straw, groundnut shell, grass, sawdust,reed into all shape of briquette, and is applicable to make biomass fuel.
2. The diameter of the final product is about 33mm.
3. Using the pressure between the molds and the skeif, and the friction to shape the raw material, also use of cellulose material inside the straw to make the raw material molding.
|
Model Parameter |
JMX-5 |
JMX-6 |
JMX-7 |
Power(KW) |
30 |
37 |
45 |
Output/ capacity |
0.5-0.8 t/h |
0.8-1 t/h |
1-2t/h |
Dimension |
2.2*1*1.5m |
2.2*1*1.5m |
2.5*1*1.9mm |
Weight (kg) |
1500 |
1800 |
2000 |
Mold type |
Flat die |
||
Operation |
2 person |
||
|
Included parts |
1) Biomass Briquetting Machine 2) 5 meters Belt Conveyor 3) Power Distribution Cabinet |
||
Wearing parts |
1) Gear of the roller , 2) sleeve of the molds, the flat die (mold) can be used last long by changing the sleeves |
||
