Product Details
Place of Origin: | Shanghai, China | Brand Name: | STAR | Model Number: | ST-R01 |
Product Description
RS485 Access and Attendance Control Keypad Time Attendance Access Controller
Specifications | |||||||||
Model | ST-T01,ST-T02,ST-T04 | ||||||||
Support type | One Door | ||||||||
Communication | TCP/IP,(Also support RS485) | ||||||||
Support reader | Weigand Reader | ||||||||
Main board size | 180x115x20mm | ||||||||
Door Open Delay | From 1sec to 600secs | ||||||||
Max distance from reader to main board | 100 meters, suggest not to exceed 80 meters | ||||||||
Working temperature | -40 to 70 Degrees Celsius | ||||||||
Working humidity | 10-90%RH, no condensation | ||||||||
Power | 12VDC 3A or 12VDC 5A | ||||||||
Max distance from reader to main board | 100 meters, suggest not to exceed 80 meters | ||||||||
Accessories | Main board, main board cover, power supply and control box, cables, disk, 2 keys, cartoon | ||||||||
Application | Bank,Cash house, Telecom station, Power supply station,Prison and Plice station: Interface locking;Intimidation alarm; Integrated fire control;Anti-passback and Anti-tail; Interlocking;Multi-card unlocking; Emergency double locking; In-door population checking; Unlocking based on internal and external validation |
Open door in remote distance | Yes |
Inter block | Yes |
Anti pass back and tail | Yes |
Multi-card open door | Yes |
Open long time at specified time | Yes |
Electronic map | Yes |
Urgency locking | Yes |
First card unlocking | Yes |
Unlock based on internal and external validation | Yes |
Keypad (card+password, supper password) | Yes |
Packing:
1pc/bag,1bag/box by export standard package.
Delivery Detail:
the normal quantity is delivery on 3-7 working days upon receive your payment,the big quantity we should check on our production schedule first then arange.
Shipping way:
1. Fast way: By express courier, such as: DHL, Fedex, UPS, TNT,EMS... take about 3-7 days.
2. Cheap way(small package):By China post, should take about 15-70 days.
3. Cheap way: By Air or by Sea shipment.
2015 Newest type 100% Waterproof IP68 Metal case Access Control Reader & Stand alone Access Controller
