Heating System, Diesel Oil Heaating Machine

Equipped with Italy Origin Riello burner, achieve the auto-diesel supply, autoignition,automatically adjust the ratio between diesel and air; Work smoothly without smoke.All indexes meet the national class I areas environmental protection standards.

This machine combines combustion chamber with heat exchanger; Exchange heat among the highest temperature parts, this latest indirect-heating technology make smoke and hot air walk their own way, absolutely no pollution. Unique heating radiator design achieve more than 90% heating efficiency.

SANHE Diesel heater’s   combustion chamber & heat exchanger are all in Stainless steel material, which is heat-resistant and extend its lifespan.

SANHE Diesel heater use presure exhaust fan to draw the fresh air into the chamber,effectively improve the working effciency.

SANHE Diesel has hoisting device which is convenient for loading/unloading; and also can work in hoisting condition. Material is very strong.

SANHE Diesel has movable pulley in its bottom and human operating handle-bar.

Technical parameter

50,000 kcal

120,000kcal

150,000kcal

Thermal output power (kcal/h)

50000 kcal/h

120000 kcal/h

150000 kcal/h

Power( KW)

60Kw

140Kw

174Kw

Heat effciency

≥%

≥90%

≥90%

≥90%

Fuel

Diesel

Diesel

Diesel

Fuel consumption   (kg/h)

2.3-5kg/h

4.5-10kg/h

7-1kg/h

Control method

Auto

Auto

Auto

Fan air volume (m³/h)

11000m³/h

11000 m³/h

14000 m³/h

Temperature rising range   (℃)

80-120 ℃

80-120 ℃

80-120 ℃

Power supply     (V/Hz)

380V/50Hz

380V/50Hz

380V/50Hz

Power   (kw)

0.7Kw

0.92 Kw

0.95Kw

Hot air outlet Dia. (mm)

520mm

520mm

520mm

Diemension

(L×W×H)mm

1760×840×1380

1760×840×1380

1750×840×1380

Frame material

Galvanized +spray paint

Galvanized +spray paint

Galvanized +spray paint

Guarantee period

One year warranty, lifelong service
