Poultry House Oil Burning Heating Machine
- 60 Set / Sets per Month
- Qingdao
- T/T
- Heater Core Heater Welding Gun Heater Element
- Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
- Preheating equipment for hardbandig welding
- Heater Core Heater Welding Gun Heater Element
- DL-3 model electric air heater with upper outlet and lower inlet
- DL-2 model electric air heater with Left-Right Circulation
Product Details
Condition: | New | Type: | Air Heater | Power Source: | Other, oil, gas, liquid gas |
Place of Origin: | Shandong, China | Brand Name: | SANHE | Model Number: | FSH-5 |
Dimension(L*W*H): | 1400*850*1370mm | Weight: | 400Kg | Voltage: | 380V/220V |
Power(W): | 0.6KW | Certification: | CE/BV/ISO:9001:2008 |
Product Description
FSH-5 Features of SANHE Auto Oil-burning Heating Machine
1)Heating area: 300/600/1200 square meters.
2)Stainless steel combustion chamber, thermal conversion as high as 90%
3)Stainless steel exchanger is made of 321 (1Cr18Ni9Ti) stainless steel plate, tube.
4)Double air input and output design.
5)Equipped with the world brand Riello burner. Automatic control system operates easily,
warm quickly. After being setted, burner would automatically start on, fire, supply air and
stop for keeping steady temperature. Save large labor and financial resources.
6)Heater exchanger adopt the special three-pass design.
7)Special insulation design which minimize heat loss.
8)All the technical index meet the national environmental protectionⅠstandard.
|
Technical Parameters
Model | Rated Heat OutpuT | Heating Area | Designed temperature | Oil | Gas | Liquid Gas | City gas | Voltage | power | Dimension | |
Kcal/h | KW | m2 | °C | L/h | Nm3/h | Nm3/h | Nm3/h | V | KW | L*W*H(mm) | |
FSH-5 | 50000 | 60 | 300 | 60 | 4.9 | 5.85 | 2.27 | 11 | 380/220V | 0.6 | 1400*850*1370 |
FSH-15 | 100000 | 120 | 600 | 60 | 9.8 | 11.7 | 4.54 | 22 | 380/220V | 1 | 1600*900*1400 |
FSH-20 | 200000 | 230 | 1200 | 60 | 19.6 | 23.4 | 9.1 | 44 | 380/220V | 1.2 | 1700*1000*1500 |
Installation Site
|
