Chicken House Diesel Oil Fired Air Heater With CE Certificate

FOB Price

US$ 1,750 - 3,720 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	Yuyun Sanhe
Model Number	FSH-5/10/20

Product Description

Chicken house diesel oil fired air heater with CE certificated

Details of the product

1. Heating area: 300/600/1200 square meters.

2. The combustion chamber is made of stainless steel.

3. Its thermal conversion reaches as high as 90%.

4. Equipped with Riello brand burner, when needed temperature is set, it will automatically start on, fire up, heat up, supply air and stop to keep constant temperature.

5. The heat exchanger uses the three-pass design.

6. Our unique furnace thermal protection and insulation system can minimize heat loss.

7. Pro-environment, cost saving.

Technical Parameter of oil-burning heating machine :

Technical Parameters	FSH-5	FSH-10	FSH-20
Heat output power kcal/h	50000 kcal/h	100000 kcal/h	200000 kcal/h
Heat efficiency ≥%	≥90%	≥90%	≥90%
Fuel	Diesel oil	Diesel oil	Diesel oil
Consumption kg/h	2-4.9 L/h	5-9.8 L/h	12-19.6 L/h
Way of control	Auto	Auto	Auto
Air flow m³/h	5000 m³/h	5500 m³/h	7000 m³/h
Temperature rise °C	80-120 °C	80-120 °C	80-120 °C
Power Source V/Hz	380V/50Hz	380V/50Hz	380V/50Hz
Electric power kw	0.6Kw	1.0Kw	1.5Kw
Diameter of air outlet mm	400mm	400mm	400mm
Weight kg	400Kg	600Kg	700Kg
Dimension	1400×850×1370	1600×900×1400	1700×1000×1500
length×width×height mm	1400×850×1370	1600×900×1400	1700×1000×1500
Material of frame	Galvanized +spray paint	Galvanized +spray paint	Galvanized +spray paint
