Industrial Diesel Air Heater With CE Certificate

Industrial Diesel Air Heater With CE Certificate photo-1
US$ 2,270 - 3,720 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Air Heater
Power Source:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Air Heater
Power Source Diesel
Place of Origin Shandong, China
Brand Name Yuyun Sanhe
Model Number FSH-5/10/20
Dimension(L*W*H) customized
Weight 500-1500kgs
Voltage 220V/380V
Power(W) 3-5.5kw
Certification CE
Warranty 1 year
After-sales Service Provided No overseas service provided

    Industrial diesel heater CE certifications



Industrial diesel air heater with CE certificate



Application



It’s widely used in livestock farm,poultry house to get warm or in  industry such as  textile, sock/clothes making workshop or other kind of factory to get warm and it is also used as dryer for drying wood, tea, medicine, foodstuff etc.



Details of the product



1. Heating area: 300/600/1200 square meters.

2. The combustion chamber is made of stainless steel.

3. Its thermal conversion reaches as high as 90%.

4. Equipped with Riello brand burner, when needed temperature is set, it will automatically start on, fire up, heat up, supply air and stop to keep constant temperature.

5. The heat exchanger uses the three-pass design.

6. Our unique furnace thermal protection and insulation system can minimize heat loss.

7. Pro-environment, cost saving.



 Technical Parameter of industrial diesel heater



Technical Parameters

FSH-5

FSH-10

FSH-20

Heat output power    kcal/h

50000 kcal/h

100000 kcal/h

200000 kcal/h

Heat efficiency  ≥%

≥90%

≥90%

≥90%

Fuel

Diesel oil

Diesel oil

Diesel oil

Consumption     kg/h

2-4.9 L/h

5-9.8 L/h

12-19.6 L/h

Way of control

Auto

Auto

Auto

Air flow   m³/h

5000 m³/h

5500 m³/h

7000 m³/h

Temperature rise °C

80-120 °C

80-120 °C

80-120 °C

Power Source  V/Hz

380V/50Hz

380V/50Hz

380V/50Hz

Electric power   kw

0.6Kw

1.0Kw

1.5Kw

Diameter of air outlet mm

400mm

400mm

400mm

Weight     kg

400Kg

600Kg

700Kg

Dimension

1400×850×1370

1600×900×1400

1700×1000×1500

length×width×height  mm

Material of frame

Galvanized +spray paint

Galvanized +spray paint

Galvanized +spray paint





 Installation of industrial diesel heater Industrial diesel air heater with CE certificate





Certifications



Industrial diesel air heater with CE certificate Industrial diesel air heater with CE certificate Industrial diesel air heater with CE certificate
CE certification ISO9001 SGS

Industrial diesel air heater with CE certificate
