OFS High-Volume Agricultural Building Ventilator Price

Specifications

1.OFS High-Volume Agricultural Building Ventilator Price
2.Popular in industry, Greenhouse, Poultry ect.
3.CE & CCC

OFS High-Volume Agricultural Building Ventilator



Innovation:



With its six specifically engineered die-formed steel blades and deep-spun panel venturi, the OFS is designed to outperform the competition.



The OFS also features American Coolair’s unique captured bearing arrangement which allows the blade hub to also serve as the driven sheave. Placing the belt load directly over the bearings greatly extends the life of the bearings, and with our exclusive optional dual-belt drive system.



Durability:



The NBF60 incorporates a rugged, heavy-gauge steel welded angle-frame construction. The sturdy X-frame drive support design insures years of trouble-free operation.



For superior reliability in the harshest environments, the NBF60 blades, panel, frame, cone, and housing are all coated with a thermosetting epoxy coating to provide a protective finish rated excellent for hardness, impact resistance, adhesion, and chemical resistance.



Performance:



Move large volumes of air efficiently and economically with American Coolair’s fan. Available in a slope wall housing, with or without a discharge cone, or as an air circulator, the OFS will simply move more air and use less power.



application:

Our exhaust fan can be used in almost all places which need ventilation and cooling.

1.industry:garment manufacturing factory, electronics, plastic,shoe,toy,hardware factory and so on

2.Commerce: hall,supermarket,hotel,net bar,recreational place, guesthouse.

3.Public:hospital,station,gym,school

4.Animal husbandry: poultry house, pig, chicken, rabbit, cow barn

5.Agriculture: horticulture, greenhouse.











Specifications:





Model No.	OFS-146SL	OFS-106SL	OFS-146SS	OFS-146SQ	OFS-106SQ
Impeller Range	1220mm	900mm	1220mm	1220mm	900mm
Impeller Material	6 SMC Fiberglass Blades	6 SMC Fiberglass Blades	3-wing FRP blades	7-wing Nylon blades	7-wing Nylon blades
Rotating Speed	460rpm	460rpm	560rpm	460rpm	560/720rpm
Air Flow	45000m3/h	20000m3/h	50000M3/H	44500M3/H	20000M3/H
Noise Level	≥65db	≥62db	≥68db	≥65db	≥62db
Power	0.75kw	0.55kw	0.75kw	0.75kw	0.55kw
Voltage	380V	380V	380V	380V	380V
Prod. Size	146*146*58cm	106*106*55cm	146*146*58cm	146*146*58cm	106*106*55cm
