Wood Cutting Machine

Wood Cutting Machine photo-1
US$ 1,500 - 6,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
DAFU
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name DAFU
Model Number BX216

Specifications

wood chippers are specially designed for round logs, square blocks, wood staff into 10-30mm size small wood pieces.

wood cutting machine

Introduction of Disk Timber Chipping Machine :
Screw plate-shaped chipping machine can cut log and small-diameter log with less than 200mm diameter and is applicable to paper pulp factory, forest tree factory, paper mill, thermal power plant, etc. Timber Chipping machine is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc.
Timber Chiping Machine

Specifications of Disk Timber Chipping Machine
Mobel of machine 2L×640 2L×1000
Diameter of cutter head(mm) 640 1000
Rotary speed of cutter head(r/min) 970 740
Quantity(sheet) of fly cutter 6 6
Length of wood chip,thickness(mm) 15-35 2-3 15-35 3-7
Mode of feeding Declination Declination
Dimension of feeding opening(mm) 150×140 250×250
Productive Capacity (t/h) 3-5 5-8
Power of electric motor(kw) 37 75
Maximum diameter of cutting wood(mm) 100 200
Mode of discharging Up Up
Weight of complete machine (kg) 1192 3375
External dimension (length×width×height) 2002×1175×1360 2820×1838×1892
Notice: Any change of Timber Chipping Machine technical data shall not be advised additionally.

The final product from this two machine (Disk Timber Chipping Machine or Drum Chipping Machine) .
