Specifications
cut logs such as small size and big stump, different type,automatic,laborforce saving, over 20 years experience, flexible rollsDisc wood chippers introduction:
1. The chipper supplied by us are special wood chipping machine to produce high quality wood. This machine is widely applied to papermaking, shaving board and MDF area or wood produce base.
2. The chipper highly structured, reasonable structure, easy installation, operation and maintainence, high production capacity. When cutting the raw wood, the wood chips is high quality and also the chips length can regulate freely in the defined range.
3. The chipper is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc.
4. The chipper can be made by user specific requirement.
Introduction of Disk Wood Chipping Machine :
Screw plate-shaped chipping machine can cut log and small-diameter log with less than 200mm diameter and is applicable to paper pulp factory, forest tree factory, paper mill, thermal power plant, etc. Wood Chipping machine is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc, in which the principal machine of chipping machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc.
Specifications of Disk Wood Chipping Machine
Mobel of machine |
2L×640 |
2L×1000 |
Diameter of cutter head(mm) |
640 |
1000 |
Rotary speed of cutter head(r/min) |
970 |
740 |
Quantity(sheet) of fly cutter |
6 |
6 |
Length of wood chip,thickness(mm) |
15-35 2-3 |
15-35 3-7 |
Mode of feeding |
Declination |
Declination |
Dimension of feeding opening(mm) |
150×140 |
250×250 |
Productive Capacity (t/h) |
3-5 |
5-8 |
Power of electric motor(kw) |
37 |
75 |
Maximum diameter of cutting wood(mm) |
100 |
200 |
Mode of discharging |
Up |
Up |
Weight of complete machine (kg) |
1192 |
3375 |
External dimension (length×width×height) |
2002×1175×1360 |
2820×1838×1892 |
