China Sourcing Of Disinfection Towel Dryer
1. Machine introduction:
1.With the functions of automatic control and timer drying, the drum can run in clockwise and anticlockwise directions automatically. It will send out a signal automatically while finishing.
2.It’s easy for operator to watch the drying condition through the large window.
3.With a slim and compact structure, it only needs less space.
4.With the functions of automatic opening, closing and tilting, HTO-TSJ100Q fully-auto dryer not only greatly reduces labor intensity, but also improves working efficiency.
2.Technical parameters:
Item name | Unit | HTO/HTO1-TSJ15 | HTO/HTO1-TSJ25 | HTO/HTO1-TSJ50 | HTO-TSJ100 | HTO-TSJ100Q |
Rated capacity (dry loading per cycle) | Kg | 15 | 25 | 50 | 100 | 100 |
Drum D×L | mm | 780×650 | 930×830 | 1160×1000 | 1460×1180 | 1460×1180 |
Power of main motor | Kw | 0.55 | 0.75 | 1.5 | 3 | 3 |
Fan motor | Kw | 0.37 | 0.75 | 1.5 | 2×1.5 | 2×1.5 |
Drum speed | rmp | 45 | 32 | 32 | 30 | 30 |
Steam pressure | Mpa | 0.5-0.6 | 0.5-0.6 | 0.5-0.6 | 0.5-0.6 | 0.5-0.6 |
Steam trap pipe(DN) | mm | 15 | 25 | 25 | 25 | 25 |
Steam consumption per cycle | Kg | 18-25 | 25-30 | 50-60 | 100-120 | 100-120 |
Dimension (L×W×H) | mm | 1150×870×1450 | 1400×1040×1700 | 1570×1282×2070 | 1880×1605×2420 | 2100×1660×2560 |
Machine weght | kg | 310 | 550 | 800 | 1200 | 1500 |
3.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
