Specifications
1.Large ranging of temperature2.High efficiency & Easy operation
3.Long distance &Simple Structure
4.With CE ISO9001
best price for pneumatic conveyor for corn, barley, wheat Introduction
The conveyor is typical of simple structure,low cost,good airproof and easy operation,etc.,capable of multi loading and uploading.It is vastly used in chemical,constructional,metallurgic environment,and grain warehouses.It has good performance when the slanting angle β<20°,characterized by fine conveying of low viscosity,constant performance,meterials not easy to adhere to each other.
The screw conveyor takes many types due to different uses and environments.For example,the vertical conveyor LC and LS-Y is fit for the blast furnace,specially used in the assimilation lime XP mono and double canal screw feeder.
Characteristic
1.Using double electromotors: feeding motor & vibrating motor , separately controlled .
2.Product funnel is design to be adjustably vibratile , which lead to avoid product blocking and improve the adaptation of different products.
3. Product funnel can separate from the tube for easy assembly.
4. Special anti-dust design to protect bearing from dust.
5. In order to convenience machine cleaning , following functions are added in : auger can reverse for emptying the tube, product discharge gate is mounted in the bottom of the funnel , auger can be disassemblied for washing.
Function
Suitable for convey the materials from one place
to the other place, or the bellow to the high place.
Mainly used for conveying sawdust, powder, grains and oilseeds, etc
QH series air conveyor, is a kind of advanced material handling machinery.Machine features flexible, fast and convenient assembly, after simple combination can be used to separate delivery, separate to send, or give mixing pumping and pressure.
Horizontal, inclined and vertical transportation, such as rice, wheat, rice, corn, high of grain, barley malt, granular materials such as plastics and resin,
suitable for grain, farm, station, wharf, grain and oil processing and brewing industry in storage or in the process of production of bulk, bulk transport, discharge, turn over the storehouse, crib, warehouse, the warehouse etc mechanical work.
The machine when conveying grain, have a rough cleaning and dewatering effect on grain.
Brand introduction:
QH series air conveyor, is a kind of advanced material handling machinery.Machine features flexible, fast and convenient assembly, after simple combination can be used to separate delivery, separate to send, or give mixing pumping and pressure.
Horizontal, inclined and vertical transportation, such as rice, wheat, rice, corn, high of grain, barley malt, granular materials such as plastics and resin, suitable for grain, farm, station, wharf, grain and oil processing and brewing industry in storage
or in the process of production of bulk, bulk transport, discharge, turn over the storehouse, crib, warehouse, the warehouse etc mechanical work.The machine is in the transport grain, on a rough grain cleaning and dehydration.
Air conveyor (grain elevator) Technical parameters:
Machine Model |
QH-10 |
Convey measure (t/h) |
10 |
Power of Air Blower (KW) |
11 |
Power of Close the wind machine(KW) |
0.75 |
total power(KW) |
11.75 |
Primary motor type |
Y160M1-2 |
Closed wind motor model |
Y90s-6 |
fan rotational speed (R/Min) |
4100 |
Closed ventilation speed (R/Min) |
60 |
Air Pressure (water column/mm) |
1500 |
air mass flow(m3/H) |
1000 |
airflow velocity(m/s) |
24 |
Feed pipe diameter(mm) |
150 |
Pipe diameter (mm) |
124 |
Horizontal maximum transmission distance(m) |
50 |
Maximum distance(m) |
10 |
Max.lift head (m) |
8 |
Total weight(KG) |
460 |
Dimension(length * width * height) mm |
1780*1058*1550 |
Air conveyor (mobile) grain machine features:
1, The operation mode is diversiform, have a single suction operation mode, single delivery operation mode mixing, suction pressure, can undertake choosing according to different customers and different requirements.
2, The machine features flexible, fast and convenient assembly, compact structure, complete function, the whole machine to give full consideration to the user requirements from the design.
3, equipment has convenient, quick, convenient, save people, save Labour, etc.
4, less dust pollution, convenient operation.
5, just put the pipeline on-demand distribution, can be horizontal, vertical, inclined, etc.
6 ,High pressure, long transmission distance, high head, small volume, low noise, low energy consumption.
7 ,C is rough for grain belt filter cleaning and dewatering.
Air conveyor (grain machine) the coupling and throughput of transfer line:
The above parameters for different grain moisture, dust content change.
Separate delivery than the hybrid yield can be increased by 20%.
Air conveyor (grain machine) loading diagram:
Air conveyor (grain machine) can be changed to delivery machine:
