Industrial and Environmental Conveying System Pneumatic Conveyor

Name: Industrial and Environmental Conveying System Pneumatic Conveyor
Brand: WANDA
SKU: 137990355
Availability: InStock

US$ 1,500 - 5,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, conveyor, Gravity Conveyor

Material:

Other, Stainless Steel, iron, steel,rubber

Henan Wanda Chemical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, conveyor, Gravity Conveyor

Material Other, Stainless Steel, iron, steel,rubber

Material Feature Other, Oil Resistant, Heat Resistant

Structure Other, Conveyor System, Belt Conveyor

Load Capacity 5-30TPD, 1-4M3/H

Place of Origin Henan, China

Brand Name WANDA

Model Number QH

Voltage 220/380V

Power(W) 5.5-15KW

Dimension(L*W*H) 1780*1058*1550(mm)

Certification CE ISO9001

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Large ranging of temperature
2.High efficiency & Easy operation
3.Long distance &Simple Structure
4.With CE ISO9001

Industrial and environmental conveying system pneumatic

Air conveyor (grain elevator) Technical parameters:

Machine Model	QH-3	QH-5	QH-10	QH-15	QH-20C	QH-30C
Convey measure (t/h)	3	5	10	15	20	30
Power of Air Blower (KW)	5.5	7.5	11	15	22	37
Power of Close the wind machine(KW)	0.75	0.75	0.75	1.1	1.1	1.5
total power(KW)	6.25	8.25	11.75	16.1	23.1	38.5
Primary motor type	Y132S1-2	Y132S2-2	Y160M1-2	Y160M2-2	Y180M-2	Y200L2-2
Closed wind motor model	Y90s-6	Y90s-6	Y90s-6	Y90L-6	Y90L-6	Y100L-6
fan rotational speed (R/Min)	3300	3600	4100	3700	4100	4100
Closed ventilation speed (R/Min)	60	60	60	60	60	60
Air Pressure (water column/mm)	940	1000	1500	1600	2200	3300
air mass flow(m3/H)	780	800	1000	1600	1800	1800
airflow velocity(m/s)	26	24	24	25	25	25
Feed pipe diameter(mm)	124	124	150	150	160	160
Pipe diameter (mm)	70	100	124	150	160	160
Horizontal maximum transmission distance(m)	20	30	50	70	120	70
Maximum distance(m)	6.8	8.5	10	20	30	50
Max.lift head (m)	5	5	8	12	18	30
Total weight(KG)	400	415	460	530	600	900
Dimension(length * width * height) mm	178010501550	178010581550	178010581550	208011481800	232013202720	238016002720
