Industry fireproof 650 degree Calcium silicate insulation pipe
High strength: the strongest one among the inorganic thermal insulation materials with the similar
density
Thermal-resistance: Non-deformation at the temperature used
Thermal insulation: lower thermal conductivity than other hard mass thermal insulation material.
Asbestos - free.
(Item) |
(Unit) |
SH - I - 17 |
SH - I - 22 |
Bulk density (max.) |
Kg/m3 |
170 |
220 |
Flexural strength (min.) |
Mpa |
0.25 |
0.3 |
Compressive strength at 5% deformation |
Mpa |
0.5 |
0.6 |
Linear shrinkage (max.) after heating for 16h at 650℃ |
% |
2 |
2 |
|
Thermal conductivity (max.) (average temp.70℃) |
W/m.k |
0.052 |
0.056 |
Service temperature (max.) |
℃ |
650 |
650 |
Moisture content(max.) |
7.5 |
7.5 |
7.5 |
|
Cured sheet |
Inside diameter |
196-3560mm |
Thickness |
25 - 75mm |
Length |
600mm 610mm 915mm |
Pipe cover |
Inside diameter |
16-171mm |
Thickness |
25 - 100mm |
Length |
600mm 610mm 915mm |
This product are recommended as thermal insulation in stove, cave dwelling of steel mill, petrochemical, ceramics ,glass, cement industries as well as other various ancillary heating equipment.
