Introduction of mini corn combine harvester:
4YW-3 corn harvesting machine is new harvest machinery which developed and manufactured by the company based on market demand,it sets the corn harvest, straw crushed land-returning as a whole,the design height adjustable elevator to improve through performance; movable grain case, make full use of the grain case space to reduce the number of times unloading grain, attached with75 to 90hp wheeled tractor.
Tractor Mounted Corn Maize Harvester structure:
This min corn combine harvester is very convenience for farming corn. It mainly consist of cutting platform, helical conveyor, lift conveyer, grain box, straw chopper, hydraulic system, drive system, machine frame and so on. It is the perfect combination of few years' practise and the latest technology.
Our corn cob harvester mounted on tractor advantages:
1.Picking corn ear and cutting up corn stem complete at one time, achieve the purpose of straw returned
2.Multi-usage, deft and agile.
3.New design small model combined Sweet Maize corn harvester : can harverst corn directly with family use tractor.
The mini corn combine harvester, breaching of its way, can reap 3 row of corn as well as realize the picking, stripping, conveying, assembly, unloading of corn and the smashing of straw.
Corn harvester machine feature:
1: without removing the corn skin to avoid the high losing rate of corn kernel.
2: can collect the corn directly and put into stock after hareveter.
3: can cut corn stalk at the same time as refertilizer.
Tractor mounted ear corn harvester technical parameters :
| Items | Technical parameters | Remarks | |
| Dimension | 7900*2480*3400 | ||
| Overall power | ≥44.1 | ||
| stripper | Number(Double) | 3 | |
| Rotating speed(r/min) | 820 | ||
| Working width | 2000 | ||
| Harvesting line | 3~4 | ||
| Adapt distance | Any spaced | Set by the size of distance | |
| Grain crushing rate % | ≤2 | ||
| Grain loss rate % | ≤3 | ||
| Cluster loss rate % | ≤1 | ||
Our factory and workshop, welcome you to visit our site!
YS IS YOUR BEST CHOICE , WAITING FOR YOUR INQUIRE.
