Specifications
New condition tractor 1BTS series agri disc harrow1.Working width:1.8~2.7m
2.Weight:570~800kg
3.Dia. of disc:560mm
New condition tractor 1BTS series agri disc harrow
1BTS series middle-duty offset disc harrow is a new type designed harrow with multifunction. It is suitable for the operations such as soil crushing after plowing, preparation of soil for sowing, chessom, clay fertilizer blending, stubbing in the light soil, etc. Especially is used in open field workings for the superficial ploughing, for the shattering of clods, burial of organic substances&remains.
It has the benefits that can connect by three point mounted and be trailed with tractor.
Features and benefits
1 Reasonable structure and easy maintainance;
2 High quality steel discs;
3 Angle can be easily adjustable
4 The heavy duty frame & heavy weight helps to break the clods;
5 Easily transportable - as it gets easily attached and mounted ;
6 The process of welding: carbon dioxide jig welding.
Technical data—1BTS series
Model |
Unit | 1BTS-8-8 | 1BTS-9-9 | 1BTS-10-10 | 1BTS-11-11 | 1BTS-12-12 |
| Frame | Square pipe box frame | |||||
| Type of disc | Notched(front), plain(rear) | |||||
| Working width | mm | 1800 | 2000 | 2300 | 2500 | 2700 |
| Working depth | mm | 150 | 150 | 150 | 150 | 150 |
| No. of disc | 16 | 18 | 20 | 22 | 24 | |
| Disc diameter | mm | 560 | 560 | 560 | 560 | 560 |
| Total height | Kg | 570 | 620 | 680 | 730 | 800 |
| Matched power | hp | 50~60 | 60~70 | 70~80 | 80~100 | 90~110 |
Shandong Tiansheng Machinery Co., Ltd. is specialized in sale and manufacturing agricultural machinery and tools, has more than 20 years manufacture experience in china.The main products include: Qingquan brand disc harrow, disc plow, mouldboard plow, rotary tiller, potato planting (harvest) machine, cultivator, subsoiler, seeder, mower, ridger, trencher, stubble cleaner, earth auger, fertilizer distributor, farm trailer, etc. Our company sells the products in 66 countries and regions such as the US, France , Russia, Zimbabwe, Ukraine, Nigeria, South America, etc. If we can help you, please contact me.
Contact information:
George Cheng
Skype: george19168
Phone: 0086-534-7629777
Mobile:0086-18266109168
Fax: 0086-534-7286666
Web:
