The QGW Series Pipe / Tube External Surface Cleaning Shot Blasting Machine
This machine can effectively remove the oxides, rusts and sundries of the tubes, and recover the metallic luster to be helpful for the antiseptic treatment of the steel.
NO. |
Item |
QTY |
Indicators |
1 |
The largest size of the workpiece |
|
Diameter × length: φ185-φ406*2000 ,According to OD232 standard computation |
2 |
Clean-up requirements |
|
With GB8923-88 AB Sa2 1 / 2 standard, the surface roughness Ra12.5 |
3 |
Productivity |
|
2m/min(OD232) |
4 |
Blasting (Switzerland + GF + DISA technology company) |
2 |
Model: HTQ034 |
5 |
The use of shots |
|
Steel shot: OD1-OD1.5 |
6 |
The amount of bullets at first time |
|
2.5t |
7 |
the screw conveyer of the bottom |
1 |
Throughput: 30 t / h Power: 3 KW |
8 |
Bucket Elevator |
1 |
Amount of upgrading: 30 t / h Power: 4 kW |
9 |
Separator |
1 |
Amount of separation : 30 t / h |
10 |
Projectile controller |
2 |
Model: electromagnetic valve pneumatic |
11 |
Precipitator |
1 |
Filter area: 26 m2 Filter drum dust remover or bag collector |
12 |
Roller conveyor system |
1 |
Reducer Model: XWD3-4-1/59 |
13 |
Concentration of dust |
|
≤120mg/m3 |
14 |
Equipment noise |
|
≤92dB |
15 |
Total power |
|
About 45.5 kW |
