Help CenterCNC QC11K Series Hydraulic Guillotine Shearing Machine
Related Products
-
Q11 Series Conventional Mechanical Shearing MachineUS$ 100 - 100,000MOQ: 1 Set -
QC12Y Hydraulic Swing Beam Shearing Machine/sheet Metal Shearing Machine/metal CutterNegotiableMOQ: 1 Set
-
Hydraulic Swing Beam Shearing Machine, Hydraulic Iron Cutting Machine Manufacturer, Hydraulic Metal Sheet CutterUS$ 3,000 - 30,000MOQ: 1 Set
-
Hand Sheet Metal Shears/alligator ShearUS$ 1,500 - 2,000MOQ: 1 Unit
-
Q11-1*1300 Precision Shearing Machine, Small Shearing MachineUS$ 256 - 6,470MOQ: 1 Unit
Specifications
CNC QC11K series hydraulic guillotine shearing machine1.High quality blade,four cutting edges
2 High accurately shearing
Guillotine shearing machine,CNC QC11K series hydraulic guillotine shearing machine, CNC hydraulic guillotine shearing machine, Hydraulic shearing machine
Function and Futures:
Total steel welded structure,internal stress eliminated by heat treatment and excellent rigidness and stability
Advanced intergral hydraulic system with good reliability.
Three-point contact bearing guideway that can eliminate the bearing clearance so as to improve the shearing quality.
Rapid,convenient and accurate hand-wheel adjustment of blade clearance.
Rectangular blade with four edges usable and with long service life
Adjustable shearing angle to reduce the distortion and deformation of the plate.
Inward incline structure for the upper blade holder for an easy blanking and workpiece accuracy improvement.
Capable of section-wise shearing and lighting alignment.
Mechanical backgauge and digital display.
Back support device(optional)
QC11Y/K Series Hydraulic Guillotine(CNC) Plate Shears
Features:
1. The entire machine is in fully steel welded structure,with stress eliminated by vibration aging technology,typical of excellent rigidity and stability.
2. Advanced hydraulic integrated valve block is employed,and the pipeline connection is minimized in a compact structure,to enhance the system reliability and maintainability.
3. Oil cylinders in series ensures the shearing angle not to change during the shearing process of the machine tool.
4. Accumulator return is stable and fast.
5. Blade gap is adjusted with handwheel,in an accurate,rapid,and easy way.The shearing angle is adjustable,to minimize the distortion of sheet bar.
6. Electric rear stopper and position display can be easily and accurately operated.
7. Rolling material support ball is set,tominimize fish tail with sheet bar and to reduce frictional resistance.
8.Warrenty: one year
9.Payment:30% down payment and 70% paid after receiving the copy of the documents
10.Delivery:30 days after receiving the 30% down payment.
| Specification | Shearing | Shearing | Strokes | Backgauge | Shearing | Height of | Main power |
| thickness | width | Range | Angle | working table | |||
| (mm) | (mm) | (mm-1) | (mm) | (º) | (mm) | kw | |
| QC11K-6X2500 | 6 | 2500 | 16-35 | 20-600 | 30'-1º30 | 760 | 7.5 |
| QC11K-6X3200 | 6 | 3200 | 14-35 | 20-600 | 30'-1º30 | 770 | 7.5 |
| QC11K-6X4000 | 6 | 4000 | 10-30 | 20-600 | 30'-1º30 | 770 | 7.5 |
| QC11K-6X5000 | 6 | 5000 | 10-30 | 20-800 | 30'-1º30 | 800 | 11 |
| QC11K-6X6000 | 6 | 6000 | 8-25 | 20-800 | 30'-1º30 | 800 | 11 |
| QC11K-8X2500 | 8 | 2500 | 14-35 | 20-600 | 30'-2º | 800 | 11 |
| QC11K-8X3200 | 8 | 3200 | 12-30 | 20-600 | 30'-2º | 800 | 11 |
| QC11K-8X4000 | 8 | 4000 | 10-25 | 20-600 | 30'-2º | 800 | 11 |
| QC11K-8X5000 | 8 | 5000 | 10-25 | 20-800 | 30'-2º | 850 | 15 |
| QC11K-8X6000 | 12 | 6000 | 8-20 | 20-800 | 30'-2º | 850 | 15 |
| QC11K-12X2500 | 12 | 2500 | 12-25 | 20-800 | 30'-2º30 | 820 | 15 |
| QC11K-12X3200 | 12 | 3200 | 12-25 | 20-800 | 30'-2º30 | 870 | 15 |
| QC11K-12X4000 | 12 | 4000 | 8-20 | 20-800 | 30'-2º30 | 870 | 15 |
| QC11K-12X5000 | 12 | 5000 | 8-20 | 20-1000 | 30'-2º30 | 900 | 22 |
| QC11K-12X6000 | 12 | 6000 | 6-20 | 20-1000 | 30'-2º30 | 950 | 30 |
