Specifications
CNC hydraulic press brake1.Stable performance;
2.E200,DA41,DA52,DA65W CNC are optional
3.high quality and perfect service
brake press, bending machine, Hydraulic press brake, CNC hydraulic press brake for sale, Small cnc press brake
hydraulic press brake WC67Y-100/2500 technical datas as following:
Nominal Force :1000kn
Length of worktable :2500mm
length of walls :2500mm
Ram stroke :150mm
throat depth : 480mm
Opening height :580mm
Amount of ram adjustment :220mm
Distance of back gauge :0-110mm (ball screws)
Stroke :5 times/minute
No. of main cylinder :2 pieces
No. of compensation :3 pieces
Main power :7.9kw(Siemens,Germany)
power for back gauge (ball screw) :0.55kw(Siemens,Germany)
power for ram adjust :0.55kw(Siemens,Germany)
hydraulic elements :omega(U.S.A)
electrical elements :Siemens (Germany)
delivery :35days
payment :30% in advance,balance before shipment,or L/C at sight
Guarantee :14 months from the date of B/L
MAIN COMPONENTS:
integrated hydraulic system,
hydraulic elements : OMEGA(U.S.A)
digital readout : south korea.
mail motor,main electric parts : Siemens (Germany)
seal:Nok (Japanese).
Guarantee : 14 months from the date of B/L
Autonics readout and rotary encoder.
CHARACTOR:
1)whole steel-welded,standard upper and lower dies,hydraulic transmission system,foot pedal with emergency stop.
2)The machine equips with DRO(digital readout) system to display the values of ram and backguage,(ball screws),and equip the side and back guard.to equip CNC system,you can choose the system E-20+ CNC(made in China) or Delem 51 system (from Netherlands),All price include the servo-motor, To equip with light curtains for rear of press brake,you can choose the system from China or sick from Germany.
All include the servo-motor.
To equip with light curtains for rear of shearing machine,you can use system from China madeor sick from Germany.
