Help CenterCNC/NC Hydrualic Plate Bending/press Brake Machine
Related Products
-
WC67Y/WE67Y CNC Press BrakeUS$ 1 - 99,999MOQ: 1 Set -
Press Brakes /100ton Press Brake/400t Hydraulic Press BrakeUS$ 1 - 99,999MOQ: 1 Set
-
CNC/NC Hydrualic Plate Bending/press Brake MachineUS$ 1 - 99,999MOQ: 1 Set
-
NC Press BrakeUS$ 1 - 99,999MOQ: 1 Set
-
Hydraulic Bending Machine /press BrakeUS$ 1 - 99,999MOQ: 1 Set
Specifications
CNC Press Brake Machine:Hydraulic top-drive,steadiness and reliability
High precision
18 months warranty
CE certification
Hydrualic plate bending
Main features:
Steel welded structure, vibrating treatment to remove the inter stress, with high strength and good rigidity
1.Hydraulic top-drive, steadiness and reliability, mechanical stop, steel torsion bar to maintain synchronization, high precision
2. Motorized-adjusting device of back gauge and ram stroke, fine adjusting by hand wheel, numerical display
3.Travel limit protection, full machine guarding with safety interlocker
4.Two cylinders controlling beams vertical moving
5.Mechanical torsion synchronization
6.Integration hydraulic system
7.Standard punches and dies
8.Hanging arm control panel
9.Foot pedal with emergency stop
Specification |
Nominal Pressure |
Length of working table |
Distance between uprights |
Throat dephts |
Ram stroke |
Motor power |
KN |
mm |
mm |
mm |
mm |
KW |
|
WC67Y-40/2200 |
400 |
2200 |
1650 |
200 |
100 |
4 |
WC67Y-40/2500 |
400 |
2500 |
1900 |
200 |
100 |
4 |
WC67Y-63/2500 |
630 |
2500 |
1900 |
250 |
120 |
5.5 |
WC67Y-63/3200 |
630 |
3200 |
2570 |
250 |
120 |
5.5 |
WC67Y-80/2500 |
800 |
2500 |
1900 |
320 |
120 |
5.5 |
WC67Y-80/3200 |
800 |
3200 |
2560 |
320 |
120 |
5.5 |
WC67Y-80/4000 |
800 |
4000 |
2900 |
320 |
120 |
5.5 |
WC67Y-100/2500 |
1000 |
2500 |
1900 |
320 |
120 |
7.5 |
WC67Y-100/3200 |
1000 |
3200 |
2460 |
320 |
120 |
7.5 |
WC67Y-125/3200 |
1250 |
3200 |
2450 |
320 |
120 |
7.5 |
WC67Y-125/4000 |
1250 |
4000 |
2960 |
320 |
120 |
7.5 |
WC67Y-160/3200 |
1600 |
3200 |
2445 |
400 |
200 |
11 |
WC67Y-160/4000 |
1600 |
4000 |
2940 |
400 |
200 |
11 |
WC67Y-160/6000 |
1600 |
6000 |
4600 |
400 |
200 |
11 |
WC67Y-200/2500 |
2000 |
2500 |
1900 |
400 |
200 |
15 |
WC67Y-200/3200 |
2000 |
3200 |
2540 |
400 |
200 |
15 |
WC67Y-200/6000 |
2000 |
6000 |
4600 |
400 |
200 |
15 |
WC67Y-250/2500 |
2500 |
2500 |
1900 |
400 |
250 |
18.5 |
WC67Y-250/3200 |
2500 |
3200 |
2530 |
400 |
250 |
18.5 |
WC67Y-300/3200 |
3000 |
3200 |
2530 |
400 |
250 |
22 |
WC67Y-300/6000 |
3000 |
6000 |
4600 |
400 |
250 |
22 |
WC67Y-4000/3200 |
4000 |
3200 |
2520 |
400 |
300 |
30 |
WC67Y-400/4000 |
4000 |
4000 |
2920 |
400 |
300 |
30 |
WC67Y-500/4000 |
5000 |
4000 |
2920 |
400 |
350 |
37 |
WC67Y-500/6000 |
5000 |
6000 |
4600 |
400 |
350 |
37 |
WC67Y-600/6000 |
6000 |
6000 |
4600 |
400 |
350 |
45 |
WC67Y-800/6000 |
8000 |
8000 |
4600 |
500 |
400 |
55 |
WC67Y-1000/6000 |
10000 |
10000 |
4600 |
600 |
500 |
75 |
