Hydraulic Iron Worker,Hydraulic Combined Punching and Shearing Machine,Hydraulic Ironworker
- 30 Set / Sets per Month
- nantong or shanghai port
- T/T
- 1600 Ton Heavy Duty Hydraulic Used Car Shell Gantry Type Shear Machine OEM Available
- 4axis 5axis Large size and thickness(0-40mm) cnc plasma cutting machine
- Automatic cnc plasma cutting machine gate cnc router 120a/200a
- Fully automatic 20mm plasma cutting machine custom size high quality
- 200mm pipe table axe for plasma metal cutting machine spare parts in weifang
- China gantry cnc plasma and oxy cutting machine dust removal equipment
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | wenao |
Model Number: | Q35Y-25 | Voltage: | 220v | Rated Power: | 7.5KW |
Dimension(L*W*H): | 2350x980x2100 | Weight: | 4400KG | Certification: | ISO9001, CE |
Warranty: | 14 month | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
iron punching machine1.manufacturer factory
2.can cut,bend,notch and punch
3.Easy to operate
4.High quality ,good price
Iron worker machine/Iron worker with hydraulic pressing cylinder
Double Cylinders Hydraulic Ironworker Q35Y-25
I. Function
Punching, Angle Steel Shearing, Flat Bar Shearing, Round/Square Bar Shearing, Notching, V-Notching, C-Channel Shearing, I-beam shearing, T-bar shearing, Press Brake, Angle Bending and Pipe Notching.
Hydraulic Ironworker, Mechanical Ironworker, Iron worker, steelworker, shearing machine, cutting machine, sheet metal punching machine, notching machine, guillotine machine, bending machine, press brake, c-channel bar, angle bar cutting machine, dual hydraulic cylinders, single cylinder, punch and shear station, rolling machine, band saw, pipe punching, tube bending, pipe notching.
2. Featuring:
1) Robust and accurate steel frame
2) Large punch table with scales
3) Removable bolster for punching flanges and channel and beam
4) 2 independent hydraulic cylinders
5) 2 shielded foot controls
6) 2 Separate Die Openings for oversized punching
7) 5 working stations for wide applications
8) Power inching on all 5 work stations
9) Plate shear support/table and notching table
10) Adjustable stroke controls with indicators on both cylinders
11) Movable work light as standard
12) Overload protection on hydraulic system
13) Electric backgauge
14) Optional bending attachment
15) Optional 5 sets punches and dies
3. technical data
Function | Item | Unit | Q35Y-25 |
shearing plate | Angle of shear | ° | 8° |
Max. shearing thickness | mm | 25 | |
Flat bar | (W×T) mm | 330×25 | |
600×16 | |||
shearing bar | Round steel | mm | 60 |
Square bar | mm | 50×50 | |
90°shearing of equal-angle bar | mm | 160×160×14 | |
45°shearing of equal-angle bar | mm | 80×80×7 | |
90°shearing of T-bar | mm | 160×80×14 | |
I beam steel | mm | 200×102×9 | |
channel steel | mm | 200×75×9 | |
notching | Thickness | mm | 12 |
Width | mm | 80 | |
Depth | mm | 100 | |
punching hole | Max. punching thickness | mm | 25 |
Max. diameter of punching | mm | 35 | |
Punching force | Ton | 120 | |
Depth of throat | mm | 400 | |
Max. length of cylinder stroke | mm | 80 | |
Stroke times | times/min | 6 | |
Material strength | N/mm2 | ≤450 | |
Motor power | KW | 7.5/11 | |
Overall dimensions(L×W×H) | mm | 2350×980×2100 | |
Net. weight | KG | 4400 |
4. ACCESSORIES
a. A pair of round hole punching die
b. A set of angle steel blade
c. A set of square and round bar blade
d. A set of shearing plate blade
e. A set of notching blade
The above punching and moulds will be installed in the machine.
For other dies and blades, customers need to order and pay additionally.
Hydraulic Ironworker, Mechanical Ironworker, Iron worker, steelworker, shearing machine, cutting machine, sheet metal punching machine, notching machine, guillotine machine, bending machine, press brake, c-channel bar, angle bar cutting machine, dual hydraulic cylinders, single cylinder, punch and shear station, rolling machine, band saw, pipe punching, tube bending, pipe notching.
