Specifications
pipe bending1)Adopt numerical control module
2)dialogue type operation
3)program enactment easy
pipe bending machine/bend pipe/pipe bend
Features:
-All programs can be operated through dialogue mode touching control screen.
-All information is displayed by English and Chinese with simple operation.
-Can sets many different angles to bending by turns.
-Possess automatic error detection function and limit protecting function.
-Guiding module has auxiliary pushing function and at the same time it possesses reiteration and entering
repeat functions that can make the guiding module length shorten.
-Counter function can accurately count workpieces quantity.
-Adoption of oil pressure valve accumulative body loop can control actions individually to prolong the lifespan of oil pressure parts.
-Tri-step loop possesses cooling and deposit functions which can avoid the deteriorate oil.
-Optional function of core entering and lubricating automatically.
-Optional function of core reversing slowly.
-Optional function of slow bending
DW38NC high performance single-head hydraulic pipe bending machine, NC control, multi-groups program and multi-angles setting, makes your operation easy and convenient, widely used in blast pipe, furniture and other metal pipes processing.
Specification/Model |
Unit |
DW38NC |
Remark |
Max bending capability |
mm |
Φ38×2 |
1. The Minimum bending diameter based onthe pipe diameter 2.The Max bending diameter can accordingto the customer’s requirement 3.The Max length of mandrel can according to customer’s requirement |
Max bending radius |
mm |
R260 |
|
Min bending radius |
mm |
R15 |
|
Max bending angle |
Degree |
190 |
|
Max effective distance of mandrel |
mm |
1600 |
|
Control System |
|
NC Control |
|
Max elbow bend pipe |
Unit |
16 |
|
Max storable sections |
Unit |
16×16 |
|
Motor power |
KW |
4 |
|
Max. Hydraulic Pressure |
Mpa |
12 |
|
Hydraulic System Control |
|
Electromagnetic Valve |
|
Oil Tank Capacity |
L |
110 |
|
Measurement |
mm |
2600×600×1000 |
|
Weight of Machine |
Kg |
750 |
