Cement Roller Press

FOB Price

USD $1,000 - $1,000,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port ShangHai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	WENAO
Model Number	G120-45, G120-45
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

Cement Roller Press
1.Reasonable price
2.High efficiency
3.Used for cement plant,mining industry
4.Saved energy powder

Cement plant roller press, Cement Roller Press

Product description:

Rolling machine is developed in the middle of 1980, which is a new cement and saved energy powder grinding equipment. It can displace the low efficiency and high consumption ball mill in part or completely. Reduce the steel consumption and nose. It is suitable to not only new plant but also technical revision of old plant. Raise the output by 40 to 60 percent and reduce the power consumption by 30 to 50 percent. The material that its fineness is 0.8mm covers 20 to 35 percent after aqueezing the material. The fineness is less than 20mm which is covered 65 to 85 percent. The inner structure of small lump is filled with microdefect. Improve the easy abrasivity. The roller face is heat weld buildup. It is easy to maintenance in the abrasive layer.

Technical Data:

Roller press type		G170-180	G160-140	G160-120	G150-100	G140-110	G140-85	G140-70	G120-60	G120-45	G100-35
roller dia(mm)		1700	1600	1600	1500	1400	1400	1400	1200	1200	1000
roller width(mm)		1800	1400	1200	1000	1100	850	700	600	450	350
speed(m/s)		1.52	1.47	1.47	1.5	1.52	1.46	1.48	1.47	1.47	1.35
nominal space(mm)		25-45	25-45	25-45	22-40	18-35	18-35	18-35	16-30	16-30	16-22
max.feeding size(mm)		65	60	60	60	60	60	60	55	55	50
feed temperature©		<=150	<=150	<=150	<=150	<=150	<=150	<=150	<=150	<=150	<=80
Grinding capacity	clinker(t/h)	920-1120	600-720	530-598	460-500	460-530	370-420	240-300	110-165	95-150	45-60
Grinding capacity	raw meal(t/h)	920-1150	650-760	550-620	480-520	485-550	390-460	260-320	175-220	110-175	50-70
motor	type	YR6302-4	YR5603-4	YR5004-4	YR5002-4	YR500-4	YR450-4	YR5001-8	Y355L-6	Y355L-8	Y355M-8
	power(kw)	1600*2	1120*2	900*2	710*2	800*2	630*2	500*2	280*2	220*2	185*2
	speed(r/min)	1490	1490	1485	1485	1485	1485	740	960	740	740
	voltage(V)	10000V	10000V	10000V	10000V	10000V	6000V	6000V	380V	380V	380V
main reducer		JGXPII20	JGXPII20	XJZ55	JGXP740	XJZ55	PBZF630	XGL48	XGM38	XGL38	XG38
*mdimension(LWH)m*		12.98.53.8	11.67.33.1	8.96.83.05	9.756.643.04	10.66.32.85	9.86.32.85	8.325.52.8	6.854.72.4	6.854.72.4	4.753.851.9
weight		272	212	190	178	176	150	115	68	62	30
