New Stone Jaw crusher
- 30 Set / Sets per Month
- nantong or shanghai port
- T/T
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Jaw Crusher | Application: | crush |
Motor Type: | AC Motor | Power(W): | 30 | Capacity(t/h): | 90-110 |
Place of Origin: | Jiangsu, China | Brand Name: | WENAO | Model Number: | GXF-120 |
Dimension(L*W*H): | 2550*3390*2670 | Weight: | 28000kg | Certification: | ISO9000 CE |
Warranty: | 18 month | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
New Stone Jaw crusherThis series of crushers are mainly used for crushing various materials
New Stone Jaw crusher
Product Introduction
GXF High-efficiency Complete Crusher series, as a new type of crushing machine, is widely used in industries of cement, metallurgy, construction material, mining, railway, highway, housing project etc, with the compressing strength no more than 200Mpa.The size of feeding material is up to 450-1000mm and the average size of discharge material can be control within 8mm, Unique design: back cover of upper case can be opened with hydraulic pressure (or hand operated) and replace components which is for easy maintenance. This feature has created the history of cement raw material production by reducing 1/3 investment on equipment and saving half of power consumption as well as less maintenance ( capacity ranged from 40t/h-500t/h).
Features and values
Adopting multi-mode elastic adjusting mechanism, the size of crushing material can be controlled effectively.
Combined coarse-crushing and fine-crushing, the crushing process simplified.
The power consumption greatly reduced.
Operation cost lowered.
Easy to maintain and long service life.
GXF High-effective Complex Crusher’operating Principle
GXF High-efficiency Complete Crusher series consist of device of impact plate; side scaleboard; screen device, cover, rotor and so on. During the operation, the motor drive the rotor; After the stone enter the GXF High-effective Complex Crusher through its feeding throat, firstly it would collide with crushing plate of rotor, and then thrown to the impact plate through the high speed rotation of the rotor for the second crushing. Finally, the material would rebound to the crushing plate again. At the same time, the stone-to-stone collision also happened. With the repeated and continually collision, the efficiency has greatly improved and power consumption reduced.
Model | Max.feed size(mm) | Average discharge | Capacity | Power | Weight | Dimensions |
GXF-40 | <450 | 3-5 | 35-45 | 75 | 12 | 2231×1940×2168 |
GXF-60 | <500 | 5-8 | 55-65 | 110 | 18 | 2550×2850×2670 |
GXF-80 | <500 | 5-8 | 75-85 | 132 | 21 | 2550×2630×2670 |
GXF-100 | <600 | 5-8 | 90-110 | 185 | 25 | 2550×3120×2670 |
GXF-120 | <600 | 5-8 | 110-130 | 200 | 28 | 2550×3390×2670 |
GXF-160 | <700 | 5-8 | 140-180 | 250 | 32.5 | 2793×3140×3014 |
GXF-200 | <700 | 5-8 | 190-220 | 280 | 38.5 | 2793×3140×3014 |
GXF-300 | <1000 | 8-12 | 280-340 | 450 | 55 | 3670×3850×4135 |
GXF-400 | <1000 | 8-12 | 380-420 | 560 | 65 | 3670×4180×4135 |
GXF-500 | <1000 | 8-12 | 460-520 | 710 | 75 | 3670×4500×4135 |
