Help CenterSL10-15 High Benefit Hydraulic Compressed Earth Brick Moulding Machine With Good Price//0086-18203652053
Related Products
-
Good Quality New Designed Precast Wall Panel Machine/prefabricated Concrete Wall Making Machine//0086-18203652053NegotiableMOQ: 1 Set -
High Efficiency Prestressed Floor Slab Making Machine/Model Interior Vibration Floor Slab Making MachineNegotiableMOQ: 1 Set
-
Plastering Machine|cement Plaster Machine|automatic Wall Plastering MachineNegotiableMOQ: 1 Set
-
Automatic Concrete Block Machine/cement Brick MachineNegotiableMOQ: 1 Set
-
Small Investment Big Profit Concrete Cement Brick Making Machine for Making Building Blocks Machine//0086-18203652053NegotiableMOQ: 1 Set
Quick Details
| Condition: | New | Type: | multi-function hydraulic compresse earth brick moulding machine |
Brick Raw Material: | Concrete |
| Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
| Capacity: | 1800-2400 block/h | Place of Origin: | Henan China (Mainland) | Brand Name: | shuliy |
| Model Number: | SL6-15 | Power: | 36.8kw | Dimension(L*W*H): | 7200x2290x3100mm |
| Certification: | ISO9001:2008 & CE | Warranty: | 12 MONTHS | After-sales Service Provided: | Engineers available to service machinery overseas |
| Brand Name:: | SL | Model Number:: | SL10-15 | Type:: | Hollow Block Making Machine |
| Processing:: | Brick Production Line | Brick Raw Material:: | Concrete | Method:: | Hydraulic Pressure |
| Automatic:: | Yes | Capacity:: | 1800-2400 block/h | Rated pressure of hydraulic system:: | 21Mpa |
| Weight: | 14.8T |
Packaging & Delivery
| Packaging Detail: | wooden case |
| Delivery Detail: | 7-10 days after deposit. |
Specifications
brick moulding machine
1.Can make many kinds of bricks
2.Full automatic with PLC
3.1800-2400 block/h
4.Hydraulic pressure
SL10-15 high-benefit hydraulic compressed earth brick moulding machine with good price
SL10-15 high-benefit hydraulic compressed earth brick moulding Machine:
1. Adopt Germany, Italy, Japan technology to manufacturing;
2. Compatible with the road blocks, road-side bricks and river bricks;
3. Adopt sub-storage device to overcome the liquefaction of concrete defects in advance;
4. The whole set of machine can be operated automatically.
5. Adopt four-oriented approach to insure the pressure head and mold box move exactly with good stability, and wide fixed mold plate for mold box, with the replacement of various models of multi-purpose tool of a machine to meet the various needs.
6. The host machine adopt hydraulic rotational molding and vibration compression molding. Molding cycle takes 15 - 25 seconds to leave the floor for forming health, and spend a lot of floor investment.
7. Forced feeding, the traditional feeding method is difficult to feed materials evenly to mold box, SL6-15 box-type cement brick making is machine equipped with a multi-fabric mixing fork, mold box to the top of mixing fork work on mandatory feed box.
Main technical parameters of SL10-15 high-benefit hydraulic compressed earth brick moulding machine:
Parameter Name |
Parameter values |
||
The largest machine dimensions |
7200×2290×3100(L×W×H)(mm) |
||
Rated pressure of hydraulic system |
21Mpa |
||
Main vibration form |
All vibration molded desk |
||
Vibration frequency |
50~70Hz |
||
Vibration acceleration |
10-15g |
||
To adapt to the high brick |
50-200mm |
||
Pallet size |
Bamboo |
1070×840×40(mm) |
|
Molding cycle |
15s |
||
Machine power |
36.8kw |
||
Machine weight |
14.8t |
||
Main product specifications and production of each plate:
Model |
Block Specifications (mm) |
Forming number |
Molding cycle |
Capacity (pcs) |
|
SL10-15 |
390×190×190 (brick) |
10 |
15 |
19200 |
|
240×115×90 (brick) |
24 |
15 |
46080 |
||
240×115×53 (standard brick) |
48 |
15 |
92160 |
||
This series of 150-650 tons of products with different specifications. Brick shaped mold can be produced according to user needs. | |||||
Production conditions: | |||
Production sites |
Venues |
15-20acres |
|
Operate camp |
60 |
||
Raw space |
300 |
||
Office space |
30 |
||
Other conditions |
Staff |
10-15people |
|
Distribution |
40kw |
||
Water |
10T/day |
||
