Specification:
1.CE ISO biomass agro charcoal machine
2.High quality, low price biomass agro charcoal machine
3.3t per day biomass agro charcoal machine
Biomass agro charcoal briquettes press making machine to make BBQ charcoal
1.The process for producing charcoal briquette as follow:
1. Crush the raw material into small pieces (diameter is about 3-5mm)
2. Dry the material by machine or dried it in the sun , till the moisture is less than 12%
3. Put the material into feed let of briquette machine
4. Produce the briquette stick from biomass material without any additive
5. Carbonized the briquette stick
6. Complete charcoal production lines include crusher, drier, charcoal briquette machine, carbonization furnace.
2.Requirement of raw materials
Size: 3-5mm
Moisture: less than12%
(1)Introduction of biomass agro charcoal machine
wood charcoal making machine is used to make sawdust into half charcoal stick, it is equiped with the auto-controlling heating system. The product of charcoal briquette making machine can be used to heat boiler, fireplace, etc.for warm in house,using the inherent characteristics of wood raw materials, through the screw extrusion ,high temperature, high pressure, the wood raw material to make micro-fiber lignin, we can get the semi-products.
(2).Features of biomass agro charcoal machine
a.The wood charcoal making machine shows the features of big capacity, low energy consumption, compact and durable.
b.Many performance data of charcoal briquette machine such as capacity, coal bar density, electric c
onsumption and wearable degree have reached advanced level.
c.If you need large capacity, one single charcoal briquette making machine can not meet your need, you can choose several sets of single machine, or use the automatic production line, the automatic production line have a large capacity ( from 800kg-2500kg/h),and it will save cost.
(3).Spare parts of biomass agro charcoal machine
(4)Final product of biomass agro charcoal machine
(5).Technical parameter of biomass agro charcoal machine
Model |
Power(kw) |
Capacity(T/H) |
Moisture |
Size(M) |
SL-50-9 |
11-15 |
0.12-0.22 |
8-12% |
2.2x0.6x1.3 |
SL-50C-9 |
22 |
0.35-0.45 |
8-12% |
2.7x6.8x1.5 |
SL-60-9 |
15-18.5 |
0.22-0.25 |
8-12% |
2.4x0.7x3.5 |
SL-70-9 |
18.5-22 |
0.28-0.34 |
8-12% |
2.4x0.7x1.4 |
SL-80-9 |
22 |
0.32-0.36 |
8-12% |
2.4x0.75x1.4 |
SL-90-9 |
30 |
0.38-0.45 |
8-12% |
2.6x0.8x1.5 |
3.Gas flow type Carbonization furnace
(1)Structure of charcoal briquette carbonize stove: Outer stove, inner stove, and fume extraction tube
Outer stove: it includes heating room, furnace body and heat-keeping layer Inner stove: The raw materials the resistance thermal steel plant and sealing cover.
Fume extraction tube: When during the process of carbonizing, there will be some smoke (can be burning) the smoke can return to the furnace through tube----gas flow carbonization stove.
Our service
1.Before Sale: help you to set a purchase plan according to your requirment.
2.During Sale: accompany you to check the performance of charcoal briquette making machine; train technical stuff for you.
3.After Sale: Sent artisan to your place and help you with the installation.
Payment
30% in advance, 70% pay off against the copy of B/L
Time of Delivery
Within 10-15 days after receive your deposit
If you are interested in our biomass agro charcoal machine , please feel freely to contact me!
