automatic blister packing machine/blister packaging machine
1. introduction
1. Traction drive by servo motor (traction by precision leadscrew or rubber press roller), with precise synchronization. The length of travel range can be set in man-machine interface.
2. Equipped with eye marking system, the background of printed pattern is uniform and looks pleasant.
3. Available for alu-plastic (hot forming) and alu-alu (cold forming), only change mould and feeder for alu-alu packing.
4. Various types of feeder solve the difficulty for irregular shape products packing.
5. Five stations forming, heat-sealing, batch number embossing, avulsion line impressing and cutting etc all adopt gear mandrel orientation, each can move freely in the mandrel when rotate the hand wheel, easy to adjust and accurately.
6. Newly mould orientation device speed up the mould changing requirement.
7. Equipped with plexiglass cover: the operation area is isolated with transmission organ, avoids pollution, easy for clean.
8. Online detection and ejection system can be chosen for option.
2. application
This machine is used in the pharmaceutical industry of capsule, tablet, and pilled foodstuff, food industry, liquid chocolate candies, chewing gum, cookies, jam, facial mask, eye of the cosmetics industry, medical device industry, needles, syringes, infusion tube and electronic component products such as aluminum-plastic, paper-plastic blister packaging.
3. technical parameter
1) Power of feeder: 1.5kw
2) Punch frequency: 30 - 80 times/min
3) Packing efficiency: 7200 - 12,000 plates/h
4) Max. forming area and depth: 275×120×20mm
5) Adjustable range of stroke: 30 - 120mm
6) Air compressor: ≥0.22m³/min (self -prepared)
7) Power: 5.7kw, AC 380V
8) Rated frequency: 50Hz
9) Dimension: 3800×800×1800mm
10) Weight: 1750kg
4. machine photo
if you are interested in our machine, please contact me.
Ms Daisy Niu
Skype: niu.daisy
0086-13073790207
