1.no cracking,shinking
2.no deformation,insect-resistant
3.easy to control
3.high quality CE
1.Application:
Mainly used for drying and sterilzing herbs like eucalyptus leaves,daisy,marguerite,linden flower,oliveleaf,cowslip,calendula,marigold,witloof,endive,chicory,succory,dandelion,nettle,melissa,leonurus,motherwort,herbaleonuri,radixpolygonatiofficinalis,polyghace Seche,polygonatum odoratum,liquorice,glycyrrhiza,acanthopanax etc .
It is for drying and sterilizing medicinal materials and pills,for drying and sterilizing and heating materials in strip shape, cube shape,small&round shape,leaves type, powdery form as well as filter cake which have high water content and certain and certain viscosity. It is also used for sterilizing medicinal liquid before and after packing.
2.Equipment characteristics
It deals with the problems which can not be solved in the traditional technology. Rise of the temperature and speed of handing materials are fast to improve the efficiency.It can sterilize the materials in low temperature without destroying the effective composition in the medicine. And it can heat the medicine by entreating the package to improve the quality of products. It saves energy and protects the environment. It is up to GMP standard.
Microwave drying and sterilizing equipment for herbs mainly use in drying and sterilizing for all kinds of tablets, pills, powder, oral liquid, medicine bottle, winebottle, Chinese- western medicine and medical gloves and garments.
3.Advantages of microwave drying and sterilizing:
1. Fast speed, short time, high efficiency and saving energy which can be
above 30%.
2. Drying and sterilizing under normal pressure.
3. The microwave heating and sterilizing process don't need to build boiler
and other utilities and have little investment; It need more little space than
traditional heating and can protect environment.
4. The production cost is low which is only 20%-60% of the steam drying and
electrical drying.
5. The medicine industry can control the quality by itself effectively.
6. Can adjust temperature and speed according to your need,don't destory material nutrition and ingredient/compositon.
7. Button control panel ,easy to control .
8. Tnnule belt type microwave equipment ,can work continuously .
4.Technical parameters:
Power supply |
380V±10% 50HZ±1% three-phase five-wire |
Microwave Output Frequency |
2450±50MHz |
Microwave input apparent power |
≤70KVA |
Microwave output power |
≥50KW |
Microwave power adjustment range |
0-50KW(adjustable) |
Ambient temperature |
-5-40°C |
Dehydrate |
50kg/h |
Relative humidity |
≤80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas |
Overall dimension(L*W*H) |
11810*1440*1750 mm |
Transmission speed |
0-10m/min(adjustable) |
Height of the inlet and outlet |
60 mm |
Microwave leak |
accord with a country GB10436-89 standards(<5 mw/cm^2) |
Equipment safety |
accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery health security index |
If you are interested in our microwave equipment,please feel free to contact me !
NOTE:We can design according to your requirements!
