The features of Cardamom dryer
1. The use of non-contact infrared temperature measurement technology, multi-point temperature, high precision, automatic control;
2. Man-machine interface operation, PLC automatic control, data storage, export, print function;
3. microwave power continuously adjustable speed adjustable frequency, temperature and humidity intelligent control chain;
4. The use of closed loading and unloading auger way, the material continuously without dust pollution;
5. thorough sterilization, no color, good friend;
6. microwave leakage value ≤1mW / cm2 (national standard ≤5mW / cm2).
The structures of cardamom dryer
1.Transmission System:
a. Speed of Conveying belt is adjustable.
In the transmission system, it applies frequency-converting control of speed, worm gear reducer.
b. The conveyor belt is Teflon Belt,special for microwave.
c. The deviation of belt is adjusted with Hand-movement.
2. The body of the Tunnel
a.The body of the microwave tunnel is made of Stainless Steel. In side there is one set of humidity extraction system to extract the humidity after heating.
b. To be safe, there is Automatic Power-off device while open the door of the machine.
c. The protecting case of Magnetic-pipe and transformer is made of stainless steel. On top there is one set of Heat extraction system to extract the heat energy generated by working of machine.
d.The frame of machine is made of Stainless Steel pipe ,others is made of cold-rolled sheet painted.
e.One set of infrared thermometric is installed at the outlet of the tunnel to measure the temperature.
3.The controlling system
a. On the outside panel there are frequency converting speed controller, emergency stop button, Start, Stop buttons,
b. All the controlling components will be installed into one controlling box, which is at the entrance of the machine.
c.Ordinary button control system,.
d.The microwave power can be adjusted by choosing in the display text.
e. Every microwave source is an independent unit.If one is broken, the machine will not be prevented from running.
f. Every magnetron has an overheating protection device.
1. Delivery Term: FOB / CFR / CIF
2. Delivery time: 20 work days after having received payment
3. Package: wooden cases(fully meets with export package requirements)
4. Payment Terms: 50% deposit by T/T,balance 50% paid by T/T before shipment.
5. Transportion : By vessel
Q:why do not person reply to me?
A:our person is 24 hours on-line,when nobody reply to you,please leave your requirements on email or chat tool,we will reply you as soon as possible.
Q:can you guarantee your quality?
A:of course.we are the manufacture factory.what is more,we put a high value on our reputation.best quality is our principle all the time.you can be assured on our production completely.
Q:how do you make your price?
A:we make the price according to our comprehensive costing.and our price will lower than the trade company ,because we are manufacturer,you will get competitive price and better quality.
