Piping strip cutting machine:
piping strip cutting machine Metal Cutting Machinery Cutting angle 45°
Machine specifications:
1.Vertical slide into the type, stable feed the knives' service life is long
2.Special design, multiple sets of gear drive is suitable
3.The machine structure is strong, small vibration, long life machine
4.Cooling fluid automatic cycle, ensure the workpiece cut surface is smooth
5.Chip processing, easy to maintain
Technical parameters:
Main specifications/models |
NMB-350 |
remark |
||
|
The blade position |
Φ350mm×3 mm |
1. Manual feeding, automatic clamping, automatic cutting
|
||
|
||||
Hollow square tube |
160×100 (mm) |
120×100 (mm) |
||
Hollow round tube |
Φ125 |
Φ100 |
||
Solid round tube |
Φ90 |
Φ75 |
||
machine size |
870mm×1180mm×2150mm |
|||
machine weigt |
450kg |
|||
Sample picture:
piping strip cutting machine Metal Cutting Machinery Power type semi-automatic
Factory picture:
piping strip cutting machine Metal Cutting Machinery Effect pipe cutting
Machines matched with cutting machine:
piping strip cutting machine Metal Cutting Machinery Cooling pump 90w
