Pipe groove cutting machine:
pipe groove cutting machine Other Metal & Metallurgy Machinery Cutting angle 45°
Machine specifications:
1.No burrs, no dust, no spark, bilateral two way clamp work piece clamping more balanced, no flash when cutting edge smoothing low noise pollution.
2.Accuracy, and fast clean: cutting precision and speed, smooth plane not fever at the same time, save the secondary processing.
3.Oblique cutting and milling slot: head can be adjusted for oblique cutting and milling slot, Angle accurately, save work and perfect pipe interface.
4.Equipment attached cooling circulation system, ensure the life of saw blade section is flat and level.
Technical parameters:
Main Specification |
Units |
NMB-275A |
Manual feed
|
|
cutting angle |
|
90° |
45° |
|
Hollow square tube |
mm |
45×45 |
30×30 |
|
Hollow round tube |
|
Φ70 |
Φ35 |
|
Solid round tube |
|
Φ20 |
Φ15 |
|
Solid square tube |
mm |
30×30 |
20×20 |
|
Machine size |
mm | 600×650×1300 |
||
Machine weight |
kg |
240 |
||
Sample picture:
pipe groove cutting machine Other Metal & Metallurgy Machinery Power type hand operated
Factory picture:
pipe groove cutting machine Other Metal & Metallurgy Machinery Effect pipe cutting
Machines matched with cutting machine:
pipe groove cutting machine Other Metal & Metallurgy Machinery Cooling pump 90w
