Specifications
$keywords$1.Various output scheme:2.0/2.5/3.3mV/V ;4 ~ 20mA, 0 ~ 5/10Vdc
2.OEM accep
$keywords$
Model:QPT-102
Range:0~10 bar...2000 bar
Feature:
1. Accuracy : 0.5% FS, 1.0% FS
2. Various output scheme:2.0/2.5/3.3mV/V ;4 ~ 20mA, 0 ~ 5/10Vdc.
3. Externally adjust zero and full scale.
4. 80% self-calibration with external.
Technical Specifications
Measuring range |
bar |
0/10,0/20,0/35,0/50,0/70,0/100,0/200, |
Overload pressure |
%FS |
150(ure: 2100 bar ) |
Signal output @ FS |
mV/V |
2.0, 2.5, 3.3(selectable) |
amplified output signal |
4~20mA, 0~5V, 0~10V(selectable) |
|
Power supply |
mV signal |
8~12Vdc |
amplified signal |
12~36Vdc(Model 24Vdc) |
|
Combined error |
%FS |
0.3,0.5(standard),1.0 (selectable) |
Zero adjustment |
%FS |
±10 |
Span adjustment |
%FS |
±6 |
Repeatability |
%FS |
0.2 |
Output resistance |
Ω |
350±10% |
Insulation resistance |
M Ω |
≥500 @ 100 Vdc |
Max.temp.@ wetted parts |
°C |
400 |
TCZ |
%FSO/10°C |
0.5 |
TCS |
%FSO/10°C |
0.5 |
Long-term stability |
%FSO/year |
<0.15 |
Compensated temp. |
°C |
0~80 |
Pressure connection |
external thread |
1/2"-20 UNF-2A(standard),M14×1.5,M18×1.5 |
Electrical connection |
connector |
6-pin (standard) male tighten connector, |
Max.mounting torque |
N.m. |
40 |
Ordering code: model- range-rated output-accuracy-pressure connection-electrical connection-electrical connection-the other requests.
Example: QPT-102-0/200bar-4/20mA-0.5%FS-M14x1.5-6-pin-***
Dimensions:(unit:mm)
