Specifications
solid state relaysolid state relay
SATA2 SSD Hard drive
1. Internal type
4. made in Taiwan
solid state relay 2.5 inch SATA II Solid State Drive SSD 60GB
SSD HARD DRIVE
Key Features
1. SATA2 Interface
- Compliant with serial ATA revision 2.6 specification
- 3.0 Gbps(Max.) interface rate.
- Supports Native Command Queuing (NCQ) up to 32 commands
- Supports TRIM command based on ATA-8
- Supports 48-bit Logical Block Addressing(LBA)
- Supports partial and slumber mode
2. Flash Interface
- Supports ONFI 2.2 synchronous/asynchronous interface
- Supports toggle synchronous interface
- 4 parallel channel flash interface
- 4 CE pins per channel support up to 16 flash devices
- Global wear leveling
3. Flash Memory Support
- Supports all 2x/1x nm MLC NAND Flash
- Supports 4KB and 8KB page size
- 2-plane structure
4. Supports External DRAM 128MB cache
5. Robust Data Protection
- Enhanced hardware BCH ECC engine: 40-bit per 1KB
- Software/Hardware write protect option
- Static data refresh technology ensures data integrity
- Early weak block retirement option
- Multiple data security zones
- Data shaping for higher date reliability
6. Controller Core
- 32-bit RISC CPU
- Internal PLL provides all necessary clocks for the whole system
- Built-in 2.5V and 2.3V Voltage detectors for power fail protection
- Automatic sleep and wake-up mechanism to save power
7. Upgradeable Firmware
- Supports firmware in system programming (ISP) function for firmware upgrade
8. High Performance(Synchronous mode)
- Sequential Read: 251 MB/s, Sequential Write: 96 MB/s with CrystalDiskMark 3.01
Test condition: Gigabyte Z68AP-D3, Windows 7, Intel i7-2600 CPU @3.40GHz
9. Operating Temperature
- -10°C ~+70°C
Specifications
1.NAND Flash: MLC flash memory in synchronous mode to deliver outstanding performance
2.SSD Capacity: 64GB
3.Internal Cache: DDR2 128MB
4. Interface: SATA2 standard 7+15 pins connector
5. Speed: SATA2 3.0Gbps, Read =251MB/s, Write = 96MB/s
6.Power Supply: 5VDC, 1A.
7.Form Factor: 2.5 inch HDD
8.Dimensions: 100mm x 70mm x 9.3mm (LxWxH)
9. Connector Durability: 1000 insertion/removal cycles
10.Weight: 95g
