Hot Selling Reader Common Access

Hot Selling Reader Common Access thumbnail-1
Hot Selling Reader Common Access photo-1
Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
hkshanhai
Model Number:
SCR3310
Type:
SD Card, MMC Card, SM Card
Contact Supplier Request Quote Chat Now
Shenzhen Shanhai Technology Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN/HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name hkshanhai
Model Number SCR3310
Type SD Card, MMC Card, SM Card
Interface USB
Card Slots Single
Installation Internal
Place of Origin Guangdong, China

Specifications

Reader Common Access
1:Smart
2:usb connector
3:2.0

 Reader Common Access

Product Description

SCM SCR3310/3310V2.0 USB Smart Card Reader Full speed USB2.0 (12Mbps)



Features

- Ergonomic and cost efficient design

- Software and functionality compatible with SCM´s SCR33xx readers family - In field firmware updates (SCR3310)

- EMV Level 1 certified

- Compliant with major smart cards and relevant industry standards - Customization options: Casing color and company logo



Typical Applications

The SCR3310 /SCR3310v2.0 are suitable for a wide range of applications for gov-
ernment as well as for enterprise and home useage.

Due to its design, the readers are also ideally suited to be bundeled with smart cards and software to support large scale projects roll outs.

Typical applications for the SCR3310 /SCR3310v2.0 include secure logical access to computers and networks, secure authentication for Business-to-Business and Business-to-Consumer applications, and secure logon such as email encryption, social security and loyalty programs, e-Couponing, secure network log on, e-Banking as well as online shopping and gaming activities.



Parameters:

Interface



SCR3310

3310V2.0

Host machine

USB

-Full speed USB2.0(12Mbps)
-USB Bus powered device

-Apply to CCID





Smart card

Connect type

-Support T=0,T=1 agreement
-Passed SCMMCARDAPI support memory card
-communication

Speed:344kbps(PPS/FI)
-Frequency: 8MHz(PPS/DI)
-Support ISO7816A and AB smart card
-Support ISO7816A/B and C smart card

-8 touching points-ISO position
-For 100.000 times plug

×


×

Staff

Optics

-One green LED





Software

API

-PC/SC
-CT-API





Operating System



-Windows®Vista/XP/Server2003/2000/ME/98
-Windows®Vista/XP/Server2003(AMD64/EMT64)
-Windows®CE3.0/4.1/4.2/5.0/6.0
-MacOS/Linu×32bit(2.4.×,2.6.×)/64bit





Cable



-Length:0.5m, with USBA connector





Size

L×W×H[mm]

-70×70×10





Weight

[g]

-70





Condition

Temperature[]
Humidity[]

-0 to 50
-90





Certificate

Function

-FCCB Part 15/cULus/CE/VCCI
-ANZI(SCR3310)
-ICES-003 Edition 4
-ICES-003 Edition 4, Class B
-USB-IF
-Microsoft®WHQL2000/XP/Server2003
-EMV2000 Class 1

×




×

Evironment

-RoHS,WEEE
-Apply to REACH(SCR3310v2.0)







if you have the interest to  the ACR38-SPC usb contact chip card reader,pls inform us,and we will help you turn  your idear into products  with high quality!





....
