Specifications
concrete batching plant1.ISO9001:2000;SGS certificate
2.registered trademark:Yujie
3.reliable performance
4.good price
concrete batching plant
PLD800 concrete batching machine is one of automatic equipments used with concrete mixer .By the computer control system batching sand macadam and other materials automatic.
This batching machine is part of concrete plant which is applied with JS500 JZC500 concrete mixer.
It is ideal concrete equipment for building project, building ground and precast product factory.
The machine is composed of feeding system, weighing system and electrical system etc. The main parts: conveyor and hopper. Conveyor is a belt feeder, with a precise weighing system (control lever & single sensor)
Technical Parameter
Item |
Unit |
Parameter |
||
PLD800-2 |
PLD800-3 |
|||
Weighing Hopper |
m3 |
0.8 |
0.8 |
|
material hopper |
m3 |
3.2×2 |
3.2×3 |
|
Productivity |
m3 /h |
48 |
48 |
|
Batching Accuracy |
% |
±2 |
±2 |
|
Amount of Batching aggregate |
2 |
3 |
||
Charging Height |
mm |
2840 |
2840 |
|
Power |
t/h |
4×3 |
4×4 |
|
Outline Dimension (L×W×H) |
t |
6200x1900x2840 |
6200x1900x2840 |
|
Weight |
kW |
2050 |
3075 |
|
