Specifications
WZ30-25 small backhoe loader for sale1)YC4B90 engine
2)loading bucket capacity 1m3
3)backacter bucket capacity0.3m3
WZ30-25 small backhoe loader for sale
1. Main features about WZ30-25
1)To adopt the gearbox, torque converter provides a super power, walking steadily and higher reliability.
2)To combine Excavator and loader as one machine, fully equipped with all function of mini excavator and loader, more suitable for operating in a narrow space, convenient and flexible, reducing the whole purchase cost and running cost.
3)Excavation and loading function are pilot control, light and flexible, high efficiency.
4)Humanized designed 360 degree swivel seat, all-steel cab of forming glass, more wide vision and more comfortable driving.
5)Excavation slideslip device make the excavation operations broader and more efficient.
6)For municipal, building, water conservancy, road, water, electricity, garden and other departments, engaged in agricultural construction, pipe laying, cable laying, landscaping and other jobs.
2.main technical parameters :
Performance |
rated load |
|
overall weight |
9500KG |
|
Bucket Capacity |
1.0m3 |
|
maximum tractive force |
39KN |
|
maximum breakout force |
60KN |
|
maximum grade ability |
|
|
maximum dump height |
2742mm |
|
maximum dump reach |
1062mm |
|
overall dimension (L×W×H) |
5910×2268×3760 |
|
minimum turning radius |
5018mm |
|
Engine |
model |
YTR4108G60-1 |
type |
In Line Direct injection Four-Stroke and Injection Combustion Chamber |
|
No. of cylinder-bore/stroke |
4-108×120 |
|
rated power |
55KW |
|
maximum torque |
≥261.7N.M/1800r/min |
|
min fuel-consume ratio |
≤216g/km.h |
|
|
Transmission system |
torque converter |
Single-stage Three Elements |
gearbox mode |
Fixed Shaft Power Transmission |
|
gear shift |
Gears Ahead, Two Gears Astern |
|
maximum speed |
22Km/h |
|
Drive axles |
main reducing spiral
|
Double reduction |
decelerating mode |
Single stage Final Reducer |
|
wheel base (mm) |
2250mm |
|
wheel tread |
|
|
minimum ground clearance |
300mm |
|
|
Hydraulic system |
system working pressure |
12Mpa |
boom lifting time |
5.4s |
|
total time |
10.5s |
|
fuel tank capacity |
|
|
|
function of leveling automatically |
yes |
|
|
Brake system |
service brake |
Airover oil capliper brake/External Type/Self-regulation/Self-balance |
parking brake |
Operation Power Implementing brake/Manual Operation Power Terminating Brake |
|
|
Tyre |
type specification |
16/70-20 |
front tyre pressure |
0.2Mpa |
|
rear tyre pressure |
0.22Mpa |
3. Details
