Help CenterManufacture Construction Brick Making Machine Eco Brava Price
Related Products
-
Manufacture Construction Interlocking Hollow Brick Machine PriceUS$ 2,000 - 19,000MOQ: 1 Set -
Construction Equipment Automatic Concrete Cement Brick MachineUS$ 2,000 - 19,000MOQ: 1 Set
-
Construction Equipment Cement Brick Block Making Machine PriceUS$ 2,000 - 19,000MOQ: 1 Set
-
Compact Structure Factory-price Block and Brick Making MachineUS$ 2,000 - 19,000MOQ: 1 Set
-
20% Energy-saving Hollow Block Production, Brick Maker MachineUS$ 2,000 - 19,000MOQ: 1 Set
Specifications
1. brick making machine.2.11 KW motor.
3. 8000-10000 capacity.
4. Produce hollow bricks.
5. ISO SGS.
Manufacture construction brick making machine eco brava price
Brief introduction of brick making machines:
The clay brick machine uses raw materials such as shale, clay, gangue, coal ash etc to produce various hollow bricks. Compared with common bricks the hollow bricks have the advantages of light weight, good heat preservation and sound insulation. So it has become the main material in construction industry. The clay brick machine of our company is fabricated with steel plates, has compact structure and high efficiency.
Production process of hollow bricks:
Clay-----Box feeder-----Roller Crusher-----Double Shaft Mixer-----Clay Brick making Machines-----Brick Cutting machine-----Cut Billet Machine -----Drying-----Sintering
Main features of brick making machines:
1.Low-cost shale, clay, gangue, coal ash as raw materials, low energy consumption.
2.Various hollow brick shapes can be produced by changing moulds.
3.Scientific structure design, convenient installation and maintenance.
4.Compact structure, stable running, investment-saving level: 35%
5.Reduce energy consumption by 30%, increase output by 20%
6.Clay brick machine adopts quenching technology, redactor gear adopts hardened gears to extend service life.
Application of brick making machines:
1.Suitable for producing all kinds of hollow bricks
2.Widely used in hollow brick making factories.
Warm tips when operating the brick making machines:
1.Adjust the position of core mark in core pin to balance the material feeding speed.
2. The material should be soft when test operation. When clay strips have good shape then gradually adjust the moisture content to make clay strips have appropriate hardness.
3.If clay material could not be extruded the clay brick machine should be checked and maintained.
4.Regularly check clay strip quality to avoid hole deviation and bottom deformation.
Tech data of brick making machines:
Model |
Motor (KW) |
N.W. (T) |
Capacity (pieces/8 hours) |
Dimension (mm) |
JX-400 |
55 |
2.4 |
80000-100000 |
2300*1200*1300 |
JX-350 |
40 |
2.2 |
60000-80000 |
2200*1000*1200 |
JX-300 |
30 |
1.6 |
40000-60000 |
2000*1000*1200 |
JX-280 |
22 |
1.4 |
8000-10000 |
2200*1000*1200 |
JX-250 |
11 |
0.75 |
8000-10000 |
3100*1000*1300 |
