Stationary Hydraulic Container Tilter, container tilter machine
Customer demand Description
1. Customer needs:Capable of following 20foot container containers flip 90 degrees of freedom, can quickly packing, unloading boxes.
2. This device single person can operate the whole, the provincial labor, save time, greatly improving production efficiency and reduce handling costs and transportation costs.
Product name:container turnover machine
Model:JX-20
Customer’s command:20’ container
Flip Angle :≤90°
Dimension:9300*6200*5600mm
Oil cylinder/flip diameter: 140/100
Power:18.5kw
Rated lifting weight (tons/set) : 31 t
Weight (tons/sets) : 14.8 T
Lifting fastest time:55s
Declining fastest time:40s
Features:
1,The machine optimized design, the whole three-hinged design is particularly reasonable point, give full play to institutional performance, a substantial increase in lifting force. Design is unreasonable, the fulcrum of the beam is very easy to crack, and finally led to frequent welding welding surface no longer welding.
2,Efficiency than similar products increased by 30%. Hengyu use piston pump, flow per revolution 40ML, fast.
3,Widening the body, vehicle access, equipment operation more convenient. You do not need to complete the second mobile container handling flip the whole process.
4,The structural design is more reasonable, rigidity has been greatly improved. Equipment overall framework are used Q345B high-manganese steel. The above three beams, and each beam path is a "gong" on both sides of the word steel welding Vincent Fang composed of a cross-section beams are five support points. Support stronger, more stable and less deflection.
5,Equipment moving parts use the slide and slide, slide, slide using high-quality wear-resistant and durable material, greatly extended service life.
6,Fuel tank design is reasonable, easy to clean and improve the cleanliness of the hydraulic oil, reduce hydraulic system failure, significantly improved synchronization valve and balancing the failure rate and prolong life.
7,Part of the structure are of high strength bolts, the tensile pull more than welding, anti-vibration, anti-distortion
8,The latch member is connected using emboss design, before locking pin after. Left. Right there one centimeter space, the lock container corner fittings do not hurt the lock pin and corner pieces.
