,Small egg tray machine/Egg tray machine production line for egg tray making

Specifications

egg tray machine
professional design layout
lower labor cost,high capacity
excellence service,good performance



Small egg tray machine/Egg tray machine production line for egg tray making



Description:



Wide range of uses, pulp molding products can be widely used in various commodities such as eggs, fruit, bottled drinks bottles, glass, ceramics, handicrafts, small machinery, spare parts, electronics, electrical appliances, toys and other goods within the packaging, gradually replace the EPS foam plastic and corrugated liner material, it not only has a good protective properties and cushioning properties, reduce product damage, improve packaging quality, and reduce costs, no pollution, recyclable, it is becoming a typical green packing for today!



Technical paramater egg tray machine:



Model	Capacity/h	Production line type	Power	Drying Method
FR-1000A 1*3	800-1000pcs/h	Semi-automatic	28kw	Natural drying
FXPT-1500 1*4	1500pcs/h	automatic	34kw	Natural drying
FXPT-2000 3*4	2000pcs/h	Semi-automatic /automatic can be choosed	49kw	Automatic belt drying  or build kiln drying
FXPT-2000A  2*3	2000pcs/h	Automatic	41.5kw	Automatic/ build kiln drying
FXPT-2500 4*4	2500pcs/h	4*4 full automatic	60kw	Automatic belt drying
FXPT-3000 4*8	3000pcs/h	4*8 full automatic	116kw	Automatic belt drying
FXPT-4500 5*8	4500pcs/h	5*8 full automatic	130kw	Automatic belt drying



1.Contact us





2. Forming system
Main machine, Washing Machine
Water pulp, Air Comprocessor
Self-priming Pump
Vaccum tank
Pump, Conveyor, Mould



3. Pulp system
Pulper, Blender, Sewage, Pump, Refiner



4. Drying system
Round, Steel, Air deflector, Grate bearing, Chamber, Fan shaft
Impeller, Bearing, Boxes



5. Packing machine



6. Introduction
Big octahedral drum machine-a total of eight suction surface, form an octahedron.
Octahedral in slurry pond internittent rotation. Each suction surface installed three to five die,
Each rotation, to produce three to five films egg tray.
Suchtion vacuum adsorption for mold shaping, the resulting eggtray uniform thickness,
High density, strength. Rotary molding machines
Generally matched with tracked transport type automatic drying system.



7. Output
2000-2600 pieces/hour 3*8

3000-3200 pieces/hour 4*8



8. Production line
1. Area covering 50*302
2. 5 person /shift
3. This line is configured as standard with 30PCS eggtray, egg production can be used for boxes, fruit trays, coffee trays. Bottle bottom and other industrial pallets.
4. We are responsible for the installation, test. But the buyer will be Responsible for the fees for the engineers in foreign country.



9. Consumption
Code name 24hours

1 wast paper 5tons

2 coal 2tons

3 water 10tons

4 electricity 65kw



Natrural Drying,Metal Drying or Build kiln Drying for your option.
