Help Center500 Liter Steam Jacketed Cooking Kettle
Related Products
-
Steam Heating Tilting Jacketed KettleUS$ 1,500 - 2,000MOQ: 1 Set -
Steam Jacketed KettleUS$ 1,500 - 2,000MOQ: 1 Set
-
Electric Heating Jacketed Cooking Kettle With AgitatorUS$ 1,500 - 2,000MOQ: 1 Set
-
Large Electric Heating Jacketed Cooking KettleUS$ 1,500 - 2,000MOQ: 1 Set
-
Tilting Cooking Jacketed KettleUS$ 1,500 - 2,000MOQ: 1 Set
Specifications
) Consist of pan-body , frame ,worm. ect.2) Can heat by electricity
3)material:SS304 & 316
4)Capacities: 50~500L
Could produce non-standard custom with pressure in 0.09-0.5Mpa
Main technical details:
Type |
50 |
100 |
200 |
300 |
400 |
500 |
600 |
Volume (L) |
50 |
100 |
200 |
300 |
400 |
500 |
600 |
|
Working pressure (Mpa) |
0.09 |
||||||
0.30 | |||||||
Evaporation (Kg/h) |
30 |
40 |
65 |
75 |
100 |
150 |
200 |
Heating area (m²) |
0.40 |
0.60 |
1.00 |
1.44 |
1.65 |
1.90 |
2.30 |
Energy consumption (Kg/h) |
33 |
44 |
72 |
110 |
136 |
165 |
190 |
ID×Deep (cm) |
60*45 |
70*52 |
80*55 |
90*63 |
100*68 |
110*75 |
120*78 |
Stirring speed (r/min) |
36 |
||||||
Moto power (Kw) |
0.37 |
0.37 |
0.55 |
0.75 |
0.75 |
1.1 |
1.1 |
Structure |
Fixed/Inclinable/Stir |
||||||
Memo:volume,working pressure, moto power, structure can be customized according to customer's specific requirements. | |||||||
Uses:
Inclinable sandwich pot made up of body, brackets, worms and worm wheels, pot body can be tilted within 180°C. This equipment with exposure mouth type, mainly used for the liquid boiling and concentrating in pharmaceutical, food, chemical, light industry etc. The contact parts of equipment with material is stainless steel SUS304ss,Has good corrosion resistance, durable in use, meet requirements of GMP. We also could increase the mixing device based on user’s requirements.
