steam heating tilting jacketed kettle

Specifications

) Consist of pan-body , frame ,worm. ect.
2) Can heat by electricity
3)material:SS304 & 316
4)Capacities: 50~500L

Could produce non-standard custom with pressure in 0.09-0.5Mpa



Main technical details:

Type	50	100	200	300	400	500	600
Volume (L)	50	100	200	300	400	500	600
Working pressure  (Mpa)	0.09
	0.30
Evaporation (Kg/h)	30	40	65	75	100	150	200
Heating area (m²)	0.40	0.60	1.00	1.44	1.65	1.90	2.30
Energy consumption (Kg/h)	33	44	72	110	136	165	190
ID×Deep (cm)	60*45	70*52	80*55	90*63	100*68	110*75	120*78
Stirring speed (r/min)	36
Moto power (Kw)	0.37	0.37	0.55	0.75	0.75	1.1	1.1
Structure	Fixed/Inclinable/Stir
Memo:volume,working pressure, moto power, structure can be customized according to customer's specific requirements.

























Uses:

    Inclinable sandwich pot made up of body, brackets, worms and worm wheels, pot body can be tilted within 180°C. This equipment with exposure mouth type, mainly used for the liquid boiling and concentrating in pharmaceutical, food, chemical, light industry etc. The contact parts of equipment with material is stainless steel SUS304ss,Has good corrosion resistance, durable in use, meet requirements of GMP. We also could increase the mixing device based on user’s requirements.
