Help CenterAutomatic Corner Sealing Machine
Related Products
Specifications
Automatic Corner Sealing Machine1. corner seal,carton height be adjusted electrically
2. width be adjusted by manual swing
Automatic Corner Sealing Machine
1. corner seal,carton height be adjusted electrically
2. width be adjusted by manual swing
main specification:
Semi automatic carton edge sealing machine L type (auto carton corner sealer) | |
Model: |
JTG-09L |
Carton size: |
(L) 300-500mm, (W) 200-500mm, (H) 150-500mm |
Table height: |
650mm |
Working speed: |
400ctns/h |
Machine size: |
(L) 2,000mm, (W) 1,200mm, (H) 1,500mm |
Power: |
220/380V, single phase, 50/60Hz or specified by clients |
Contactor and Switch |
France Schneider |
Motor |
Taiwan Brand, CE certified. |
Japan |
|
imported from Europe. |
|
sensor |
Japan Omron or YAMATAKE |
Pneumatic component |
Taiwan AIRTAC |
Pneumatic: |
5-6kg/cm2, 450 L/min |
Tape width: |
48-75mm alternative use |
Machine net weight: |
approx. 450kgs |
|
Features: Characterized with simple and easy operation, economy, durable, safety and low rate of malfunction. The width and height are adjusted manually for packing cartons of the same size at the same time. The carton will be turned 90°after the top and bottom sealing and pushed into the corner and side sealing system by the case pushing board. Adjustment for cartons only needs one minute, the fastest in China. The four sides and corners of carton are sealed at the same time quickly and smoothly with the advantages of beauty, high efficiency and manpower-saving. | |
