bottle packing machine1. corner seal,carton height be adjusted electrically
2. width be adjusted by manual swing
bottle packing machine
1. corner seal,carton height be adjusted electrically
2. width be adjusted by manual swing
main specification:
Semi automatic carton edge sealing machine L type (auto carton corner sealer) | |
Model: |
JTG-09L |
Carton size: |
(L) 300-500mm, (W) 200-500mm, (H) 150-500mm |
Table height: |
650mm |
Working speed: |
400ctns/h |
Machine size: |
(L) 2,000mm, (W) 1,200mm, (H) 1,500mm |
Power: |
220/380V, single phase, 50/60Hz or specified by clients |
Contactor and Switch |
France Schneider |
Motor |
Taiwan Brand, CE certified. |
Japan |
|
imported from Europe. |
|
sensor |
Japan Omron or YAMATAKE |
Pneumatic component |
Taiwan AIRTAC |
Pneumatic: |
5-6kg/cm2, 450 L/min |
Tape width: |
48-75mm alternative use |
Machine net weight: |
approx. 450kgs |
|
Features: Characterized with simple and easy operation, economy, durable, safety and low rate of malfunction. The width and height are adjusted manually for packing cartons of the same size at the same time. The carton will be turned 90°after the top and bottom sealing and pushed into the corner and side sealing system by the case pushing board. Adjustment for cartons only needs one minute, the fastest in China. The four sides and corners of carton are sealed at the same time quickly and smoothly with the advantages of beauty, high efficiency and manpower-saving. | |
- Carton sealer
- Carton packer
- Carton erector
- Conveyors
- Stretch wrapping machines
- Strapping machine
- Palletizers
- Robot palletizers
Company Introduction:
Dalian Jialin Machine Manufacture Co., Ltd. is a professional manufacturer specialized in developing, designing, producing and installing auto conveyors (standard or nonstandard), packing machines and medical apparatus, etc.
Located in Dalian City, our company was established in 2003, covering an area of 5,300 square meters with a building area of 5,000 square meters. Total assets over USD2,500,000. There are 120 employees, including 27 professional technicians.
Being ISO9001:2000 certified, we have import and export right, and also have manufacture license of medical apparatus. We keep supplying machines worldwide reguarly and had won sound reputation among our customers. We try our best to supply the best products and services for you all the time!
If you are interested in our products, please feel free to contact us for more information.
Thanks & Best regards,
Dalian Jialin Machine Manufacture Co., Ltd.
No. 138 Guofang Road, Jinzhou District,
Dalian, China 116100
Tel: +86-411-66366707/00
Fax: +86-411-87683017
Contact person: Miss Alex Trade manager ID: cgs_jolinen
